Запчасти Hyundai HSL600 INJECTION PUMP

1

15461-5101-0

15461-5101-0-Assy Pump Injection

11

15401-5106-0

15401-5106-0-Rack Control

12

15221-5125-0

15221-5125-0-Pin Tappet Guide

13

15221-5143-0

15221-5143-0-Pin Clamp

14

15601-5122-0

15601-5122-0-Holder Delivery Valve

15

15221-5138-0

15221-5138-0-Sleeve Control

16

15221-5127-0

15221-5127-0-Seat Spring Upper

17

15221-5128-0

15221-5128-0-Spring Plunger

18

15221-5129-0

15221-5129-0-Seat Spring Under

19

15221-5149-0

15221-5149-0-Shim

2

15221-5139-0

15221-5139-0-Plate Adjust

20

15221-5107-0

15221-5107-0-Assy Tappet

23

14611-5120-0

14611-5120-0-O-Ring

3

15221-9103-0

15221-9103-0-Bolt

4

15221-5123-0

15221-5123-0-Spring Delivery Valve

5

15221-5124-0

15221-5124-0-Back Control

6

15221-5103-0

15221-5103-0-Valve Delivery Valve

7

15221-5105-0

15221-5105-0-Element Pump

8

15471-5132-0

15471-5132-0-Screw

9

15401-9665-0

15401-9665-0-Gasket
