Запчасти Hyundai HSL600 ENG. STOP LEVER GROUP

1

15471-5409-0

15471-5409-0-Assy Apparatus Idle

10

15611-5772-0

15611-5772-0-Lever Engine Stop

11

04811-10070

04811-10070-O-Ring

12

05411-00420

05411-00420-Pin-Spring

13

15611-5751-0

15611-5751-0-Spring

14

15108-5728-0

15108-5728-0-Stopper

15

02056-50060

02056-50060-Nut

18

15221-5166-0

15221-5166-0-Gasket Pump Cover

19

01023-50618

01023-50618-Bolt

2

15471-5410-0

15471-5410-0-Assy Bolt Adjusting

20

19222-1621-3

19222-1621-3-Cover Fuel Camshaft

21

19222-1619-0

19222-1619-0-Collar

22

15469-8311-0

15469-8311-0-Gasket

23

15471-9536-0

15471-9536-0-Circlip-External

24

01173-51070

01173-51070-Bolt

25

04512-50100

04512-50100-Washer Spring

26

15521-5427-0

15521-5427-0-Cap

5

15471-9201-0

15471-9201-0-Nut

6

04811-00060

04811-00060-O-Ring

7

15521-5770-0

15521-5770-0-Assy Lever Engine Stop

8

15521-5165-0

15521-5165-0-Cover Injection Pump

9

15611-5774-0

15611-5774-0-Shaft Lever
