Запчасти Hyundai HSL600 PISTON,CRANKSHAFT GROP.

19274-2109-2

19274-2109-2-Assy Piston Ring 05

19274-2191-0

19274-2191-0-Piston 05

19202-2398-0

19202-2398-0-Metal-Side

19439-2191-0

19439-2191-0-Piston 05

19202-2397-0

19202-2397-0-Metal-Side

15471-2297-0

15471-2297-0-Metal Crankpin 02

15471-2298-0

15471-2298-0-Metal Crankpin 04

1

19274-2111-0

19274-2111-0-Piston

10

15471-2231-0

15471-2231-0-Metal Crankpin

11

15478-2301-2

15478-2301-2-Comp Crank Shaft

13

19202-2328-0

19202-2328-0-Sieeve-Crank Shaft

14

07715-03209

07715-03209-Ball

15

15471-2411-0

15471-2411-0-Gear-Crankshaft

16

05712-00720

05712-00720-Key-Feather

17

15471-2331-0

15471-2331-0-Oil Slinger

18

19202-2325-0

19202-2325-0-Collar-Crankshaft

19

04811-10300

04811-10300-O-Ring

2

19439-2111-0

19439-2111-0-Piston

20

15221-2336-0

15221-2336-0-Nut-Crankshaft

21

15221-2338-0

15221-2338-0-Washer Crankshaft

22

15221-2347-0

15221-2347-0-Metal Crankshaft 1

23

15221-2348-0

15221-2348-0-Metal Crankshaft 2

24

15521-2353-0

15521-2353-0-Metal-Side

25

19202-2354-0

19202-2354-0-Metal-Side

26

19202-0414-0

19202-0414-0-Seal-Oil

3

19274-2105-0

19274-2105-0-Assy Piston Ring

4

15521-2131-0

15521-2131-0-Piston Pin

5

15221-2133-0

15221-2133-0-Cir-Clip Piston Pin

6

15471-2201-2

15471-2201-2-Assy Connecting Rod

8

15221-2198-0

15221-2198-0-Bush Piston Pin

9

15521-2214-0

15521-2214-0-Bolt Connecting Rod
