Запчасти Hyundai 42HDLL BOOM HYD PIPING 2(WITH GRAPPLE,42HDLL)

*

@

@-Boom Hyd Piping

10

32W3-50160

32W3-50160-Pipe Assy

11

31FL-60400

31FL-60400-Pipe Assy

12

P913-167045

P913-167045-Hose Assy-Orfs 0x0

13

P983-167334

P983-167334-Hose Assy-Thd,0x90

14

31FL-60081

31FL-60081-Hose Assy

15

32W3-50010

32W3-50010-Hose Assy-Thd,0x0

16

32W3-50020

32W3-50020-Hose Assy-Thd,0x0

17

31FL-60130

31FL-60130-Hose Assy

18

31FL-60140

31FL-60140-Hose Assy

19

P683-167317

P683-167317-Hose Assy-Flg,0x0

20

P933-167018

P933-167018-Hose Assy-Orfs,0x90

21

P933-167023

P933-167023-Hose Assy-Orfs,0x90

22

31W1-60070

31W1-60070-Clamp-Tube

23

31W1-60210

31W1-60210-Clamp-Tube

24

31W1-60040

31W1-60040-Clamp-Tube

25

32W3-50060

32W3-50060-Clamp-Tube

26

31W1-60230

31W1-60230-Clamp-Tube

27

32W3-50070

32W3-50070-Clamp-Tube

28

31W1-60090

31W1-60090-Plate

29

31W1-60100

31W1-60100-Plate

3

32W2-50110

32W2-50110-Pipe Assy

30

31W1-60110

31W1-60110-Plate

31

P173-160104

P173-160104-Flange-Split

32

S621-014001

S621-014001-O-Ring

33

S621-021001

S621-021001-O-Ring

34

Y171-024001

Y171-024001-O-Ring

35

32W1-50120

32W1-50120-Bolt-Hex

36

32W1-50130

32W1-50130-Bolt-Hex

37

S109-100306

S109-100306-Bolt-Socket

38

31W1-60170

31W1-60170-Washer-Spring

4

32W2-50120

32W2-50120-Pipe Assy

5

32W3-50110

32W3-50110-Pipe Assy

6

32W3-50120

32W3-50120-Pipe Assy

7

32W3-50130

32W3-50130-Pipe Assy

8

32W3-50140

32W3-50140-Pipe Assy

9

32W3-50150

32W3-50150-Pipe Assy
