Запчасти Hyundai HL740-9 PAGE 5170 SEAT(MECHANICAL, 2", 1/2) СТРУКТУРА

*

71LM-33011

SEAT ASSY-MECH 2"

GRAMMER

1шт.

17

ZGBH-00004

BUSH

2шт.

18

ZGBH-00166

BACKREST-GS.SCR

1шт.

19

ZGBH-00013

COVER-PLASTIC

1шт.

20

ZGBH-00016

SPONGE

1шт.

21

ZGBH-00204

HINGE COVER KIT

1шт.

21-1

ZGBH-00182

COVER-RH

1шт.

21-2

ZGBH-00181

COVER-LH

1шт.

22

ZGBH-00110

SEAT PLATE GS

1шт.

23

ZGBH-00037

SCREW-SELF TAPPING

6шт.

24

ZGBH-00205

SLIDER KIT

1шт.

24-1

ZGBH-00038

ADJUSTMENT-TILTING

1шт.

24-2

ZGBH-00039

SPRING

1шт.

24-3

ZGBH-00114

ADJUSTMENT-SEAT

1шт.

24-4

ZGBH-00034

RIVET

4шт.

24-5

ZGBH-00035

PROFILE-GLIDING

4шт.

25

ZGBH-00055

SCREW

1шт.

26

ZGBH-00007

HANDLE

1шт.

27

ZGBH-00008

WHEEL-TOOLHEAD

1шт.

28

ZGBH-00010

RIVET-BLIND

8шт.

29

ZGBH-00011

BRAKE-SLING SPRING

1шт.

30

ZGBH-00012

STICKER

1шт.

31

ZGBH-00021

PLATE

2шт.

32

ZGBH-00017

WINKEL

1шт.

33

ZGBH-00019

RODS

1шт.

34

ZGBH-00020

CARRIER

1шт.

38

ZGBH-00107

RIVET

2шт.

39

ZGBH-00207

BACKREST KIT

1шт.

39-1

ZGBH-00109

SELF LOCK NUT

1шт.

39-2

ZGBH-00024

WASHER-BLACK

1шт.

39-3

ZGBH-00025

SPRING HOLDER

1шт.

39-4

ZGBH-00026

SPRING-LEG

1шт.

39-5

ZGBH-00033

HANDLE

1шт.

39-6

ZGBH-00027

LEVER

1шт.

39-7

ZGBH-00113

PLATE

1шт.

39-8

ZGBH-00029

SCREW

3шт.

39-9

ZGBH-00112

SCREW

1шт.

39-1

ZGBH-00015

WASHER

1шт.

39-11

ZGBH-00014

SCREW-HEX HEAD

1шт.

40

ZGBH-00023

HEX NUT-BLACK

2шт.

44

ZGBH-00208

BALL

5шт.

45

ZGBH-00015

WASHER

2шт.

46

ZGBH-00209

HANDLE

1шт.

60

ZGBH-00043

SCREW-CYLINDRIC HEAD

2шт.

73

ZGBH-00213

BOX-LITERATURE

1шт.

76

ZGBH-00215

BOLT

1шт.

77

ZGBH-00216

SEEGER

1шт.

78

ZGBH-00217

ARMREST KIT

1шт.

78-1

ZGBH-00030

ARM REST-LH

1шт.

78-2

ZGBH-00015

WASHER

1шт.

78-3

ZGBH-00023

HEX NUT-BLACK

1шт.

79

ZGBH-00218

CUSHION KIT

1шт.

79-1

ZGBH-00189

CUSHION-SEAT,WHEAT

1шт.

79-2

ZGBH-00037

SCREW-SELF TAPPING

4шт.

80

ZGBH-00219

CUSHION-BACK

1шт.
