Запчасти Hyundai R360LC9 PAGE 4130 TRAVEL REDUCTION GEAR(TYPE 1) ГИДРАВЛИЧЕСКИЕ КОМПОНЕНТЫ

*-2

XKAH-01449

TRAVEL REDUCTION GEAR

SEE 4120

1шт.

1

XKAH-01441

GEAR-RING

1шт.

2

XKAH-01442

HOUSING

1шт.

4

XKAH-01443

COVER-SIDE

1шт.

S005

XKAH-01444

CARRIER NO.1

1шт.

S006

XKAH-01445

CARRIER NO.2

1шт.

9

XKAH-01446

GEAR-SUN NO.1

1шт.

10

XKAH-01447

GEAR-SUN NO.2

1шт.

11

XKAH-01448

GEAR-SUN NO.3

1шт.

S012

XKAH-00995

PLANETARY GEAR NO.1

3шт.

S013

XKAH-00996

PLANETARY GEAR B NO.2

3шт.

14

XKAH-00997

PLANETARY GEAR NO.3

4шт.

S016

XKAH-00998

PIN NO.2,B

3шт.

17

XKAH-00999

PIN NO.3

4шт.

S018

XKAH-01000

PLATE -SIDE

3шт.

S019

XKAH-01001

SIDE PLATE A

6шт.

20

XKAH-01002

SIDE PLATE F

8шт.

S021

XKAH-01003

BEARING-NEEDLE

3шт.

S022

XKAH-01004

CAGE-NEEDLE

3шт.

23

XKAH-01005

CAGE-NEEDLE

4шт.

S024

XKAH-01262

RING-INNER

3шт.

25

XKAH-01007

BUSHING-FLOATING

4шт.

26

XKAH-01008

THRUST RING 60

2шт.

S027

XKAH-01009

RING-THRUST 90

1шт.

29

XKAH-01010

BOLT-SOCKET

28шт.

30

XKAH-00210

BOLT-SOCKET

12шт.

K032

XKAH-00032

PLUG-RO

3шт.

33

XKAH-01450

BEARING-BALL

2шт.

K034

XKAH-01451

SEAL-FLOATING

1шт.

35

XKAH-01013

SHIM

1шт.

S036

XKAH-01014

PIN-SPRING

3шт.

S037

XKAH-01015

RING-SNAP

4шт.

S044

XKAH-00143

RING-SNAP

3шт.

45

XKAH-01017

CLIP

1шт.

46

XKAH-01018

CLIP

1шт.

N047

XKAH-01452

NUTRING

NOT

1шт.

51

XKAH-01437

NAME PLATE

1шт.

52

XKAH-00986

RIVET SCREW

2шт.

K081

XKAH-01453

O-RING

1шт.

K082

XKAH-01454

O-RING

1шт.

83

XKAH-00035

O-RING

3шт.

53

XKAH-01022

WASHER

1шт.

54

XKAH-01455

SCREW-SET

3шт.

55

XKAH-01439

STOPPER-NUTRING

4шт.

56

XKAH-01440

BOLT-SOCKET

8шт.

S011

XKAH-01024

SUB ASSY-NO.1 CARRIER

SEE ILLUST

1шт.

S012

XKAH-01025

SUB ASSY-NO.2 CARRIER

SEE ILLUST

1шт.

K013

XKAH-01026

SUB ASSY-SEAL

SEE ILLUST

1шт.
