Запчасти Hyundai H80 STEERING & BRAKE HYDRAULIC PIPING 2

1

35D1-30300

35D1-30300-Valve-Foot

10

P620-043013

P620-043013-Hose Assy-Thd 0x90

19

P010-310003

P010-310003-Connector

20

P010-310006

P010-310006-Connector

21

P020-310002

P020-310002-Elbow-90

22

P020-310006

P020-310006-Elbow-90

23

34E7-03760

34E7-03760-Elbow-Swivel Nut

25

P010-310005

P010-310005-Connector

26

32E6-10460

32E6-10460-Tee-Swivel

28

P620-063009

P620-063009-Hose Assy-Thd 0x90

29

35D1-30350

35D1-30350-Tee

3

35D2-30010

35D2-30010-Hose Assy

31

S611-012001

S611-012001-O-Ring

32

S611-016001

S611-016001-O-Ring

33

S611-019001

S611-019001-O-Ring

34

S015-060402

S015-060402-Bolt-Hex

37

S411-060002

S411-060002-Washer-Spring

4

P620-081015

P620-081015-Hose Assy-Thd 0x90

41

35D1-11030

35D1-11030-Accumulator

42

35D1-11040

35D1-11040-Connector

43

P391-080000

P391-080000-Washer-Copper

49

31L1-0142

31L1-0142-Protector-Plastic

5

P620-043020

P620-043020-Hose Assy-Thd 0x90

8

P620-043021

P620-043021-Hose Assy-Thd 0x90

9

P620-043018

P620-043018-Hose Assy-Thd 0x90

N27

35D1-30330

35D1-30330-Tee-Swivel Nut
