Запчасти Doosan Daewoo PIPING ASSY-CLAMSHELL LONG 2.2M OPTION PARTS

-

H070-9007

PIPING ASS'Y-CLAMSHELL LONG 2.2m

desc: CONDUITE

-2шт.

1

A004-0018

PIPE

desc: CONDUITES

2шт.

2

H001-0019D014

HOSE 1400L

desc: TUYAU FLEXIBLE

2шт.

3

H001-0019D015

HOSE 750L

desc: TUYAU FLEXIBLE

2шт.

4

S8000181

O-RING

desc: JOINT TORIQUE

6шт.

5

S0558166

BOLT;HEX. M10x1.5x30

desc: BOULON A 6 PANS

4шт.

6

S0558466

BOLT;HEX. M10x1.5x45

desc: BOULON A 6 PANS

2шт.

7

S0558866

BOLT;HEX. M10x1.5x65

desc: BOULON A 6 PANS

4шт.

8

S5102603

WASHER;SPRING M10

desc: RONDELLE

8шт.

9

S5010603

WASHER;PLAN M10

desc: RONDELLE

4шт.

10

S2212466

BOLT;SOCKET M10x1.5x40

desc: BOULON A 6 PANS

4шт.

11

2124-1026D1

CLAMP;PIPE

desc: FIXATION DE TUYAU

2шт.

12

H006-0001D019A

STOP VALVE

desc: VANNE

2шт.

13

H005-0009D011

CLAMP;STOP V/V

desc: FIXATION DE TUYAU

2шт.

14

2181-2820D3

CAP

desc: CHAPEAU

2шт.

15

111-00031D1

ADAPTER;UNION

desc: ADAPTEUR

2шт.

16

2181-1126D6

ADAPTER

desc: ADAPTEUR

4шт.

17

2181-2419D1

ELBOW

desc: COUDE

2шт.

18

2181-1702D2

ELBOW

desc: COUDE

2шт.

19

A042-0039A

BRACKET

desc: SUPPORT

2шт.

20

A006-0005

VALVE;SWITCH

desc: VANNE

2шт.

21

H070-9008

ARM;SEAT WELDMENT

desc: REPOSER

1шт.
