Запчасти Doosan Daewoo FUEL INJECTION PIPE ENGINE PARTS

1

129900-01950

BRACKET

desc: SUPPORT

1шт.

2

26106-100142

BOLT;PLATED M10X14

desc: BOULON

1шт.

3

26106-080202

BOLT;PLATED M8X20

desc: BOULON

1шт.

4

729902-53100

VALVE;FUEL

desc: VANNE

4шт.

5

129902-53000

NOZZLE

desc: . BEC

4шт.

8

114250-53080

NUT;NOZZLE CASE

desc: . ECROU

4шт.

9

129100-53100

NOZZLE HOLDER ASS'Y

desc: . SUPPORT

4шт.

12

114250-53120

SPRING;NOZZLE

desc: . RESSORT

4шт.

13

114250-53130

SEAT;NOZZLE SPRING

desc: . SIEGE

4шт.

14

114250-53140

PLATE;STOP

desc: . PLAQUE

4шт.

15

114250-53210

PIN

desc: . GOUPILLE

8шт.

16

114250-53400

SHIM PACK

desc: . CALE

4шт.

28

119305-59120

RETAINER

desc: ARRETOIR

2шт.

31

129150-59131

BOLT;HEX. SOCKET M4X14

desc: . BOULON A 6 PANS

2шт.

32

129550-59120

RETAINER

desc: ARRETOIR

1шт.

35

129150-59131

BOLT;HEX. SOCKET M4X14

desc: . BOULON A 6 PANS

2шт.

37

129910-59810

PIPE;FUEL INJECTION NO.1

desc: TUYAU

1шт.

41

129910-59820

PIPE;FUEL INJECTION NO.2

desc: TUYAU

1шт.

45

129910-59830

PIPE;FUEL INJECTION NO.3

desc: TUYAU

1шт.

49

129910-59840

PIPE;FUEL INJECTION NO.4

desc: TUYAU

1шт.
