Запчасти Doosan Daewoo CONTROL VALVE MAIN PIPING(3)
- ARM BLOCK-CONTROL VALVE
- BOOM BLOCK-CONTROL VALVE
- BOOM SWING BLOCK-CONTROL VALVE
- BUCKET BLOCK-CONTROL VALVE
- DOZER BLOCK-CONTROL VALVE
- INLET BLOCK-CONTROL VALVE
- INLET BLOCK-CONTROL VALVE
- OPTION BLOCK-CONTROL VALVE
- OUTLET BLOCK-CONTROL VALVE
- SWING BLOCK-CONTROL VALVE
- TRAVEL BLOCK(LH)-CONTROL VALVE
- TRAVEL BLOCK(RH)-CONTROL VALVE
12
11
10
9
8
7
6
5
4
3
2
1
№
Артикул
Название
Примечание
Количество
-
420-00357
CONTROL VALVE ASS'Y
desc: SOUPAPE DE COMMANDE
1шт.
1
08401480
BLOCK;INLUT
desc: BLOC
1шт.
2
08401481
BLCOK;BOOM
desc: BLOC
1шт.
3
08401482
BLCOK;BUCKET
desc: BLOC
1шт.
4
08401483
BLCOK;ARM
desc: BLOC
1шт.
5
08401484
BLCOK;DOZER
desc: BLOC
1шт.
6
08401485
BLCOK;OPTION
desc: BLOC
1шт.
7
08401486
BLCOK;TRAVEL(L) BLOCK ASS'Y
desc: BLOC
1шт.
8
08401487
BLCOK;TRAVEL(R)
desc: BLOC
1шт.
9
08401488
BLCOK;BOOM SWING
desc: BLOC
1шт.
10
08401489
BLCOK;INLET-2
desc: BLOC
1шт.
11
08401490
BLCOK;SWING
desc: BLOC
1шт.
12
08401491
BLCOK;OUTLET
desc: BLOC
1шт.
Выбрано товаров: 13
