Запчасти Doosan Daewoo TRACK LINK ASSY TRACK PARTS

-

2272-9040

TRACK LINK ASS'Y

desc: MAILLON DE CHAINE(TR21154L069)

2шт.

1

L/A154L069

LINK ASS'Y

SERIAL: 1-468

1шт.

1

K9000861

LINK ASS'Y

SERIAL: 469

1шт.

1-1

T/R154L001

LINK;TRACK(R.H.)

SERIAL: 1-468

37шт.

1-1

K9000862

LINK;TRACK(R.H.)

SERIAL: 469

37шт.

1-2

T/L154L001

LINK;TRACK(L.H.)

SERIAL: 1-468

37шт.

1-2

K9000863

LINK;TRACK(L.H.)

SERIAL: 469

37шт.

1-3

T/P154I001

PIN;TRACK

SERIAL: 1-468

37шт.

1-3

K9000864

PIN;TRACK

SERIAL: 469

37шт.

1-4

T/B154HK40

BUSHING;TRACK

ICA: Y

37шт.

1-4

T/B154HK52TB

BUSHING;TRACK

desc: GARNISSAGE CAOUTCHOUC

37шт.

1-4

K9000866

BUSHING;TRACK

SERIAL: 469

37шт.

1-5

M/P154I001

PIN;MASTER

SERIAL: 1-468

1шт.

1-5

K9000865

PIN;MASTER

SERIAL: 469

1шт.

1-6

M/B154L001

BUSHING;MASTER

SERIAL: 1-468

1шт.

1-6

K9000867

BUSHING;MASTER

SERIAL: 469

1шт.

1-7

C/L154L001

SPACER

SERIAL: 1-468

2шт.

1-7

K9000869

SPACER

SERIAL: 469

2шт.

1-8

M/R154L023

LINK;MASTER(R.H.)

SERIAL: 1-468

1шт.

1-9

M/L154L023

LINK;MASTER(L.H.)

SERIAL: 1-468

1шт.

1-10

P/W154A00A

PIN

SERIAL: 1-468

1шт.

1-11

S/L154L001

SEAL

SERIAL: 1-468

74шт.

1-11

K9000868

SEAL

SERIAL: 469

74шт.

2

TROOT-1423

BOLT

desc: BOULON A 6 PANS

152шт.

3

TROOT-1461

NUT

desc: ECROU

152шт.

4

M-3T-4286

SHOE 450mm

desc: SABOT

38шт.
