Запчасти Doosan Daewoo FUEL PUMP ASSY OPTION PARTS

-

2401-1177

FUEL PUMP ASS'Y

SERIAL: 1-237

1шт.

-

2401-1177A

FUEL PUMP ASS'Y

SERIAL: 238

1шт.

1

2401-9173

PUMP;FUEL TRANSFER

SERIAL: 1-237

1шт.

1

2401-1277

PUMP;FUEL TRANSFER

SERIAL: 238

1шт.

2

2195-3570

BRACKET

SERIAL: 1-237

1шт.

2

2195-3570A

BRACKET

SERIAL: 238-252

1шт.

2

2195-3570B

BRACKET

SERIAL: 253

1шт.

3

S0502953

BOLT M5X0.8X12

desc: BOULON A 6 PANS

4шт.

4

S5000213

WASHER;PLAIN M5

desc: RONDELLE PLATE

4шт.

5

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

4шт.

6

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

2шт.

7

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

8

S4012633

NUT M10X1.5

SERIAL: 1-252

2шт.

9

S8180321

RING;SEAL

SERIAL: 1-237

2шт.

10

2181-2137

ADAPTER;FUEL

SERIAL: 1-237

1шт.

11

2185-1341

HOSE;FUEL

desc: TUYAU FLEXIBLE

1шт.

12

S8450023

CLAMP;HOSE

desc: COLLIER

2шт.

13

2181-1126D88

ADAPTER;FUEL

SERIAL: 1-237

1шт.

14

2185-1591

HOSE;FUEL

SERIAL: 1-237

1шт.

14

2185-1755D1

HOSE ASS'Y

SERIAL: 238

1шт.

15

2471-1130A

STRAINER

SERIAL: 1-237

1шт.
