Запчасти Doosan Daewoo 2 WAY PIPING-FRONT OPTION PARTS

-

2400-1876

2 WAY PIPING

desc: CONDUITES CIRCUIT PILOTE

-2шт.

1

2140-1365

PIPE

desc: TUYAU

1шт.

2

2140-1366

PIPE

desc: TUYAU

1шт.

3-1

2140-1364

PIPE(1.63M ARM)

desc: TUYAU

2шт.

3-2

2140-1404

PIPE(2.15M ARM)

desc: TUYAU

2шт.

6

2184-1071D46

HOSE PF1/2-1100L

desc: TUYAU FLEXIBLE

2шт.

12

2124-1026D2

CLAMP

desc: FIXATION DE TUYAU

8шт.

13

S0560753

BOLT M12X1.75X50

desc: BOULON A 6 PANS

8шт.

14

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

8шт.

15

2124-1340D7

CLAMP

desc: ATTACHE DE TUYAU

4шт.

16

2181-1950D3

PLUG PF1/2

desc: BOUCHON

4шт.

21

S0515853

BOLT M12X1.75X60

desc: BOULON A 6 PANS

2шт.

22

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

10шт.

23

S4012733

NUT M12X1.75

desc: ECROU

2шт.

27

S8000181

O-RING P18

REP_PNO: 8202-014

6шт.

43

S0512453

BOLT M10X1.5X40

desc: BOULON A 6 PANS

4шт.

45

2124-1026D1

CLAMP

desc: ATTACHE DE TUYAU

4шт.

46

2420-9522

VALVE;LINE STOP

desc: VANNE

2шт.

47

2181-1126D6

ADAPTER PFO1/2 PF1/2

desc: RACCORD

2шт.

48

S0512653

BOLT M10X1.5X50

desc: BOULON A 6 PANS

4шт.

49

2191-1799D72

SEAT;SCREW

desc: PLAQUE A VIS

4шт.

50

2191-1799D73

SEAT;SCREW

desc: PLAQUE A VIS

4шт.

51

2191-1799D74

SEAT;SCREW

desc: PLAQUE A VIS

4шт.

52

2191-1991D18

SEAT;SCREW

desc: PLAQUE A VIS

2шт.
