Запчасти Doosan Daewoo SWING MOTOR HYDRAULIC PARTS

-

2401-9255

SWING MOTOR

SERIAL: 253

1шт.

1

MS50S201

BODY

desc: CARROSSERIE

1шт.

2

OSAP1709

SEAL;OIL D30XD50X11

SC: K

1шт.

3

MS50S202

BLOCK;CYLINDER

desc: BLOC-CYLINDRES

1шт.

4

MS50D103

SHAFT

desc: ARBRE

1шт.

5

TB30305C

BEARING;TAPER

desc: PALIER

1шт.

6

BU302520

BUSH D30XD20X201

desc: COUSSINET

1шт.

7

J43A102

PLATE;SHOE

desc: PLAQUE DE VANNE

1шт.

8

MS50D104

SPRING

desc: RESSORT

9шт.

9

MS50D105

PLATE;SET

desc: PLAQUE

1шт.

10

J43A108

PISTON SHOE ASS'Y

desc: ENSEMBLE SABOT

9шт.

11

MS50D106

GUIDE;BALL

desc: GUIDE

1шт.

12

MS50S203

COVER;REAR

desc: COUVERCLE

1шт.

13

J43A110

PIN

desc: GOUJON

1шт.

14

AS568-252

O-RING

SC: K

1шт.

15

TB30202

BEARING;TAPER

desc: PALIER

1шт.

16

MS50D108

PLATE;VALVE

desc: PLAQUE DE VANNE

1шт.

17

MS50D109

RELIEF VALVE ASS'Y

desc: CLAPET DE DECHARGE

2шт.

18

WBM1230

BOLT;SOCKET M12X30L

desc: BOULON A 6 PANS CREUX

4шт.

19

WPT12

PLUG PT1/2

desc: BOUCHON

1шт.

20

MS50D110

PLUG

desc: BOUCHON

1шт.

21

P0014

O-RING

SC: K

1шт.

22

S343000-5

SHIM D34XD30X0.5T

desc: CALE

1шт.

23

WPT14

PLUG PT1/4

desc: BOUCHON

3шт.

24

BURP026

RING;BACK UP P26

SC: K

2шт.

25

P0026

O-RING P26

SC: K

2шт.

26

MS50S204

PLATE;FRICTION

desc: PLAQUE

1шт.

27

MS50S205

PLATE

desc: PLAQUE

1шт.

28

MS50S206

PISTON;PARKING

desc: PISTON

1шт.

29

AS568-254

O-RING

SC: K

2шт.

30

MS50S207

SPRING

desc: RESSORT

18шт.

31

MS50S208

VALVE;TIME DELAY

desc: VANNE

1шт.

32

WBM0675

BOLT;SOCKET M6X751

desc: BOULON A 6 PANS CREUX

3шт.

33

MS50S209

PLUG

desc: BOUCHON

2шт.

34

P0011

O-RING P11

SC: K

2шт.

*

2401-6250K

SEAL KIT

SC: S

1шт.
