Запчасти Doosan Daewoo REMOTE CONTROL VALVE(2) HYDRAULIC PARTS

-

2420-9416

VALVE;REMOTE CONTROL(L.H)

SERIAL: 9-147

1шт.

-

2420-9417

VALVE;REMOTE CONTROL(R.H)

SERIAL: 9-147

1шт.

1

J95C1001

CASE

desc: CARTER

1шт.

2

WPT18

PLUG PT1/8

desc: BOUCHON

4шт.

3

J95C1002

PLUG PF3/8

desc: BOUCHON

1шт.

4

P0014

O-RING P14

desc: JOINT TORIQUE

1шт.

5

J95C1003

SPOOL

desc: BOBINE

4шт.

6

J95C1004

SHIM

SC: R

-2шт.

7

J95C1005

SPRING

desc: RESSORT

4шт.

8

J95C1006

SEAT;SPRING

desc: SUPPORT DE RESSORT

4шт.

9

J24D2011

STOPPER

desc: TAQUET D'ARRET

-2шт.

10

J95C1007

SPRING

desc: RESSORT

4шт.

11

J95C1008

PLUG

desc: BOUCHON

4шт.

12

RSY10

SEAL;ROD DYR10(H70)

desc: JOINT D'HUILE

4шт.

13

P0020

O-RING 4D-P20

desc: JOINT TORIQUE

4шт.

14

J95C1009

PUSH ROD

desc: TIGE DE POUSSOIR

4шт.

15

J95C1010

PLATE

desc: PLAQUE

1шт.

16

J95C1011

BUSHING

desc: DOUILLE

1шт.

17

J95C1012

JOINT ASS'Y

desc: JOINT

1шт.

18

J95C1013

PLATE;SWASH

desc: PLAQUE

1шт.

19

J95C1014

NUT;HEX

desc: ECROU

1шт.

20

HNM14-1

NUT M14

desc: ECROU

1шт.

21

P0010A

O-RING P10A

desc: JOINT TORIQUE

1шт.

22

J96C2001

CONNECTOR

desc: RACCORD

1шт.

23

SR12ES

RING;SNAP Ґх12 E-TYPE

desc: BAGUE CIRCLIPS

1шт.

24

J95C1016

BELLOWS

desc: BELLOWS

1шт.

25

HNM12-1

NUT M12

desc: ECROU

1шт.

26

WPM12

WASHER M12

desc: RONDELLE PLATE

1шт.

28

J95C1017

SWITCH ASS'Y

desc: INTERRUPTEUR

-2шт.

29

J95C1018

ROLLER

desc: GALET

1шт.

30

J95C1019

SWITCH COVER M4X10L

desc: INTERRUPTEUR

1шт.

31

J95C1020

SWITCH COVER

desc: INTERRUPTEUR

1шт.

32

J95C1021

COVER

desc: COUVERCLE

1шт.

33

SAM10407

SCREW M4X17L

desc: VIS

1шт.

34

WPM04

WASHER M4

desc: RONDELLE PLATE

1шт.
