Запчасти Doosan Daewoo WATER PUMP ENGINE PARTS

1

65.06500-6114

WATER PUMP ASS'Y

desc: ENSEMBLE POMPE A EAU

1шт.

1-1

65.06501-0048

HOUSING;WATER PUMP

desc: . BOITIER DE POMRE A EAU

1шт.

2

65.06505-0019

SHAFT;WATER PUMP

desc: . ARBRE

1шт.

3

06.31430-0312

BEARING;BALL

desc: . ROULEMENT A BILLES

1шт.

4

06.31430-0512

BEARING;BALL

desc: . ROULEMENT A BILLES

2шт.

5

65.06508-0010

BEARING;SPACER

desc: . DOUILLE D'ESPACEMENT

1шт.

7

06.29020-0128

RING;SNAP C TYPE

desc: . BAGUE ELASTIQUE

1шт.

8

65.06520-6006

SEAL UNIT ASS'Y

desc: . JOINT

1шт.

9

65.06506-0015

INPELLER

desc: . PROPULSEUR

1шт.

10

65.06504-0019

CENTER;FAN

desc: . JOINT CENTRAL

1шт.

11

65.06901-0028

GASKET;PUMP COVER

desc: . JOINT

1шт.

12

65.06512-0013

COVER;WATER PUMP

desc: . COUVERCLE

1шт.

13

06.04200-9009

SCREW

desc: . VIS

3шт.

15

65.06901-0002

GASKET;WATER PUMP

desc: JOINT

1шт.

16

06.01493-4209

BOLT;WATER PUMP FIX

desc: BOULON A 6 PANS

1шт.

16

06.01533-8221

BOLT M10X1.25X75

desc: BOULON A 6 PANS

2шт.

16

06.01943-3221

BOLT ASS'Y M10X50

desc: BOULON A 6 PANS

2шт.

16

06.06731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

17

65.19103-0063

PLATE;ADJUSTER

desc: SUPPORT D'ALTERNATEUR

1шт.

19

65.06606-0031

PULLEY;FAN

desc: POULIE

1шт.

21

65.06601-5030

FAN ASS'Y 6BLADE

desc: ENSEMBLE VENTILATEUR

1шт.

22

06.01913-3119

BOLT ASS'Y M8X40

desc: BOULON A 6 PANS

4шт.

25

65.06611-0095

FLANGE;FAN

desc: BRIDE

1шт.
