Запчасти Doosan Daewoo CYLINDER HEAD AND COVER ENGINE PARTS

1

65.03101-6050

CYLINDER HEAD ASS'Y

desc: ENSEMBLE CULASSE

1шт.

1-1

65.03101-1044

HEAD;CYLINDER

desc: CULASSE

1шт.

2

65.90302-0026

CUP;SEALING(REAR FACE) D=44.6

desc: COUPELLE

1шт.

3

65.90302-0030

CUP;SEALING. EXHAUST MANIFOLD

desc: COUPELLE

2шт.

4

65.90302-0019B

CUP;SEALING. INLET SIDE

desc: COUPELLE

4шт.

5

65.90302-0045

CUP;SEALING(LOWER)

desc: TASSE

2шт.

6

65.90302-0027

CUP;SEALING

desc: COUPELLE

4шт.

7

65.90302-0017

CUP;SEALING

desc: BOUCHON

4шт.

8

65.90302-0019B

CUP;SEALING(TOP FACE) D=25

desc: COUPELLE

3шт.

9

65.90302-0011

PLUG;PLATE

desc: BOUCHON

4шт.

10

65.03203-1019

SEAT;INLET VALVE

desc: SIEGE

4шт.

11

65.03203-1020

SEAT;EXHAUST VALVE

desc: SIEGE

4шт.

12

65.03201-1013

GUIDE;VALVE

desc: GUIDE-SOUPAPE

8шт.

15

65.90201-0053

BOLT;STUD. INJECTION NOZZLE FIX

desc: GOUJON

8шт.

17

65.90201-0016

BOLT;STUD. EXHAUST MANIFOLD

desc: GOUJON

3шт.

18

65.90201-0015

BOLT;STUD. ROCKER ARM NUT

desc: GOUJON

3шт.

20

65.04110-5001

SEAL;VALVE GUIDE

desc: JOINT DE QUEUE DE SOUPAPE

8шт.

21

65.03901-0034

GASKET;CYLINDER HEAD

SERIAL: 9701222

1шт.

21

65.03901-0059

GASKET;CYLINDER HEAD

SERIAL: 9701223

1шт.

22

65.90020-0007

BOLT;CYLINDER HEAD FIX

desc: BOULON DE CULASSE

4шт.

22

65.90020-0006

BOLT;CYLINDER HEAD FIX

desc: BOULON DE CULASSE

13шт.

22

65.90020-0027

BOLT;CYLINDER HEAD FIX

desc: BOULON DE CULASSE

1шт.

23

65.19202-0003

HANGER;LIFTING(REAR)

desc: OEILLET DE LEVAGE

1шт.

24

65.19202-0016

HANGER;LIFTING(FRONT)

desc: OEILLET DE LEVAGE

1шт.

25

06.01943-3213

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

26

06.01913-3218

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

27

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

28

65.03401-6037

CYLINDER HEAD COVER ASS'Y

desc: COUVERCLE DE CULASSE

1шт.

29

65.01810-5007

CAP;OIL FILER

desc: BOUCHON DE REMPLISSAGE D'HUILE

1шт.

30

65.03905-0010

PACKING;CYLINDER HEAD COVER

desc: RONDELLE ETANCHE

1шт.

31

65.90725-0002

PACKING;HEAD COVER NUT

desc: RONDELLE PLATE

3шт.

32

65.90701-0018

WASHER;HEAD COVER NUT

desc: RONDELLE PLATE

3шт.

33

65.90501-0007

NUT;HEAD COVER

desc: ECROU

3шт.

34

06.15010-2313

WASHER

desc: RONDELLE PLATE

3шт.

35

65.97871-0323

PLATE;NAME

desc: PLAQUE

1шт.

36

06.04190-8806

SCREW M5X12

desc: VIS

6шт.

37

06.16731-2104

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

38

06.67020-0102

CLAMP

desc: COLLIER

1шт.

39

65.96301-0220

HOSE;RUBBER

desc: FLEXIBLE CAOUTCHOUC

1шт.

40

65.03435-0001

COVER

desc: COUVERCLE

1шт.

41

65.03903-0001

PACKING;COVER

desc: RONDELLE ETANCHE

1шт.
