Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

1

65.01101-6053

CYLINDER BLOCK ASS'Y

desc: ENSEMBLE BLOC-CYLINDRES

1шт.

2

65.01105-1020C

CAP;BEARING(FRT.INT.RR.)

SC: D

4шт.

2-1

65.01105-1021C

CAP;BEARING(CENTER)

SC: D

1шт.

3

65.90020-0029

BOLT;BEARING CAP FIX

desc: . BOULON A 6 PANS

10шт.

4

65.91710-0001

PIN;DOWEL. BEARING CAP NO.4

desc: . BAGUE

2шт.

5

65.04410-0012

BUSH;CAMSHAFT

desc: . COUSSINET DE PALIER D'ARBRE A CAMES

1шт.

6

65.04410-0006

BUSH;CAMSHAFT

desc: . COUSSINET DE PALIER D'ARBRE A CAMES

2шт.

7

65.90302-0009

CUP;SEALING(FRT.REAR)

desc: . BOUCHON

2шт.

8

65.90302-0042

CUP;SEALING. TAPPET CHAMBER

desc: . BOUCHON DE DESSABLAGE 32

2шт.

9

65.90302-0041

CUP;SEALING(R.H)

desc: . BOUCHON DE DESSABLAGE 28

1шт.

10

65.05202-0001A

BUSH;OIL PUMP DRIVE SHAFT

desc: . DOUILLE

1шт.

11

65.90320-0019

PLUG;CYLINDER LOWER

desc: BOUCHON A VIS

1шт.

12

65.90320-0022

SCREW;PLUG PT1/8

desc: BOUCHON A VIS

6шт.

13

06.15091-0313

CUP;SEALING

desc: BOUCHON

1шт.

14

65.90310-0135

PLUG;SCREW

desc: BOUCHON A VIS

1шт.

15

65.96507-0010

PACKING;PLUG

desc: BAGUE D'ETANCHEITE

1шт.

16

06.22022-3111

PIN;STRAIGHT Ґх10X16

desc: BROCHE

2шт.

17

65.01112-0021

COVER;TAPPET CHAMBER

desc: COUVERCLE

2шт.

19

06.22022-3119

PIN;STRAIGHT

desc: BROCHE

1шт.

21

65.90020-0049

BOLT;TAPPET CHAMBER COVER L=27

desc: BOULON A 6 PANS

4шт.

22

65.96507-0007

PACKING

desc: BAGUE D'ETANCHEITE

4шт.

23

65.01901-0004

GASKET;TAPPET CHAMBER COVER

desc: GARNITURE

2шт.

24

65.91710-0004

PIN;DOWEL. CYLINDER HEAD

desc: ANNEAU DE BLOCAGE

2шт.

25

65.06310-6005

WATER DRAIN COCK ASS'Y

desc: BOUCHON DE VIDANGE

1шт.

26

06.56190-0713

RING;SEAL

desc: BAGUE D'ETANCHEITE

1шт.

27

65.05401-5002

RELIEF VALVE ASS'Y

desc: CLAPET DE DECHARGE

1шт.

28

06.56021-0102

O-RING;RELIEF VALVE

desc: JOINT TORIQUE

1шт.

30

65.91605-0001C

COVER;OIL PUMP HOLE

desc: COUVERCLE

1шт.

31

06.56021-0106

PACKING;OIL PUMP HOLE

desc: JOINT TORIQUE

1шт.

32

06.01913-3113

BOLT ASS'Y

desc: BOULON A 6 PANS

2шт.

34

65.98155-0011

NIPPLE

desc: GRAISSEUR

1шт.

35

65.01201-0062

LINER;CYLINDER(ALTV)

desc: CHEMISE DE CYLINDRE

4шт.

35

65.01201-0063

LINER;CYLINDER(1A)

desc: CHEMISE DE CYLINDRE

1шт.

35

65.01201-0065

LINER;CYLINDER(2A)

desc: CHEMISE DE CYLINDRE

1шт.

35

65.01201-0064

LINER;CYLINDER(1B)

desc: CHEMISE DE CYLINDRE

1шт.

35

65.01201-0066

LINER;CYLINDER(2B)

desc: CHEMISE DE CYLINDRE

1шт.
