Запчасти Doosan Daewoo CRANK ASSEMBLY ENGINE PARTS

1

65.02101-6027

CRANK SHAFT ASS'Y

desc: ENSEMBLE VILEBREQUIN

1шт.

1-1

65.02101-0041

CRANK SHAFT

desc: . VILEBREQUIN

1шт.

2

06.22022-3211

PIN;STRAIGHT Ґх12X18

desc: . GOUPILLE

1шт.

4

65.01110-8033

METAL KIT;CRANK

desc: KIT D'ETANCHEITE

1шт.

4

65.01110-6073

METAL;MAIN

desc: . PALIER

8шт.

4

65.01110-6074

METAL;MAIN(CENTER)

desc: . PALIER

2шт.

5

65.01150-6008

WASHER;THRUST

desc: RONDELLE DE BUTEE

2шт.

6

65.02301-5055

FLYWHEEL ASS'Y

desc: ENSEMBLE VOLANT

1шт.

6

65.02301-0203

FLYWHEEL

desc: . VOLANT

1шт.

7

65.02310-0006

GEAR;RING

desc: . COURONNE DENTEE DEMARREUR

1шт.

8

06.01494-4406

BOLT;HEX

desc: BOULON A 6 PANS

6шт.

9

65.90701-0085

WASHER;FLYWHEEL FIX

desc: RONDELLE

1шт.

10

65.91501-0008

KEY;FEATHER. CRANK GEAR

desc: CLAVETTE

1шт.

11

65.02115-0013

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

12

65.02401-6160

CONNECTING ROD ASS'Y

desc: ENSEMBLE DE BIELLE

4шт.

12-1

65.02401-0160

ROD;CONNECTING

desc: . TIGE

4шт.

13

65.02405-1060

BUSH;SMALL END

desc: . COUSSINET

4шт.

14

65.02411-0006

BOLT;CONNECTING ROD

desc: . BOULON A 6 PANS

8шт.

15

65.02410-6003

METAL KIT;CON ROD

desc: PALIER

4шт.

16

65.02501-0186

PISTON

SERIAL: 9700042

4шт.

16

65.02501-0564

PISTON

SERIAL: 9700043

4шт.

16

65.02501-0187

PISTON "A" GRADE

desc: . PISTON

1шт.

16

65.02501-0188

PISTON "B" GRADE

desc: . PISTON

1шт.

17

65.02503-8022

SET;PISTON RING

desc: VIS DE REGLAGE

4шт.

17-1

65.02503-0095

RING;TOP

SERIAL: 9700042

1шт.

17-1

65.02503-0072

RING;TOP

SERIAL: 9700043

1шт.

17-2

65.02503-0116

RING;2ND

desc: . SEGMENT DE COMPRESSION

1шт.

17-3

65.02503-0096

RING;OIL

SERIAL: 9700042

1шт.

17-3

65.02503-0074

RING;OIL

SERIAL: 9700043

1шт.

18

65.02502-0009

PIN;PISTON

desc: GOUJON DE PISTON

4шт.

19

06.29020-0121

RING;SNAP

desc: BAGUE CIRCLIPS

8шт.

20

65.02601-0116

PULLEY;CRANK SHAFT

desc: POULIE

1шт.

21

65.91501-0009

KEY;FEATHER. PULLEY

desc: CLAVETTE

1шт.

22

65.90501-0005

NUT;CRANK SHAFT(FRT)

desc: ECROU

1шт.

23

65.90701-0015

WASHER;CRANK SHAFT PULLEY

desc: RONDELLE

1шт.
