Запчасти Doosan Daewoo CAM SHAFT & VALVE MECHANISM ENGINE PARTS

1

65.04101-0014

VALVE;INLET

desc: VANNE

4шт.

2

65.04101-0025A

VALVE;EXHAUST

desc: VANNE

4шт.

3

65.04102-0017

VALVE SPRING

desc: RESSORT

8шт.

4

65.04103-0001

SEAT;SPRING

desc: PLAQUE DE VANNE

8шт.

5

65.04103-0007A

SEAT;SPRING(LOWER)

desc: PLAQUE DE VANNE

8шт.

6

65.04104-0001

COTTER

desc: GOUPILLE

16шт.

7

65.04301-0009

TAPPET

desc: POUSSOIR DE TIGE DE CULBUTEUR

8шт.

8

65.04302-5009

ROD;PUSH

desc: TIGE DE POUSSOIR

8шт.

9-0

65.04200-6020B

ROCKER ARM & SHAFT ASS'Y

desc: ENSEMBLE AXE DE CULBUTEUR

1шт.

9

65.04201-5002A

ARM;LOCKER. WITH BUSH

desc: . BALANCIER

8шт.

9-1

65.04201-0018

LOCKER ARM

desc: .. ENSEMBLE AXE DE CULBUTEUR

8шт.

9-2

65.93020-0056

BUSH

desc: .. COUSSINET

1шт.

10

65.04205-0001

SCREW;ADJUSTING. ROCKER ARM

desc: . VIS DE REGLAGE

8шт.

11

65.90501-0013

NUT;ADJUSTING SCREW

desc: . ECROU

8шт.

12

65.04203-5011

ROCKER ARM & SHAFT ASS'Y

desc: . ENSEMBLE AXE DE CULBUTEUR

1шт.

12-1

65.04203-0011

ROCKER ARM & SHAFT

desc: .. ENSEMBLE AXE DE CULBUTEUR

1шт.

13

65.90302-0010

PLUG;ROCKER ARM

desc: . BOUCHON

2шт.

14

65.04202-0001

BRACKET;ROCKER ARM(FRONT)

desc: . SUPPORT

1шт.

16

65.04202-0003

BRACKET;ROCKER ARM(INTER)

desc: . SUPPORT

4шт.

17

65.97601-0048

SPRING;ROCKER ARM SHAFT

desc: . RESSORT D'AXE DE CULBUTEURS

3шт.

18

65.90001-0040

BOLT;HEX

desc: . BOULON A 6 PANS

1шт.

18

06.01013-9118

BOLT;ROCKER ARM M8X1.25X65

desc: . BOULON A 6 PANS

6шт.

19

06.15030-0513

WASHER;PLAIN. ROCKER ARM

desc: . RONDELLE PLATE

6шт.

20

06.11063-8214

NUT;ROCKER ARM BRACKET

desc: . ECROU

3шт.

21

06.15030-0513

WASHER;PLAIN

desc: . RONDELLE PLATE

3шт.

22

06.29010-0116

RING;SNAP

desc: . CIRCLIP

1шт.

23

65.04401-0008

SHAFT;CAM

desc: ARBRE A CAMES

1шт.

24

65.04501-0006

GEAR;CAM SHAFT

desc: PIGNON D'ARBRE A CAMES

1шт.

25

06.29151-4608

KEY;FEATHER

desc: CLAVETTE

1шт.

26

65.90001-0084

BOLT M14X1.5X40

desc: BOULON A 6 PANS

1шт.

27

65.90701-0059

WASHER;CAM GEAR

desc: RONDELLE PLATE

1шт.

28

65.98112-0009

PLATE;THRUST. CAM SHAFT

desc: PLAQUE LATERALE

1шт.

29

06.01913-3115

BOLT;HEX. THRUST PLATE

desc: BOULON A 6 PANS

2шт.

30

65.04505-5014

IDLE GEAR ASS'Y

desc: BARBOTIN

1шт.

31

65.90720-0016

COLLAR;THRUST

desc: RONDELLE DE BUTEE

1шт.

32

65.04506-0011

SHAFT;IDLE GEAR

desc: GOUPILLE DE PIGNON FOU

1шт.

33

06.01943-3222

BOLT ASS'Y M10X55

desc: BOULON A 6 PANS

2шт.
