Запчасти Doosan Daewoo INSTRUMENT PANEL COVER BODY PARTS

-

2197-1503

CONTROL STAND ASS'Y

desc: CONSOLE DE COMMANDE

1шт.

4

2197-1318

BRACKET

SERIAL: 1-8

1шт.

4

2197-1599

BRACKET

SERIAL: 9

1шт.

5

2621-2679A

COVER;BRACKET(L)

desc: COUVERCLE

1шт.

6

2621-2678

COVER;BRACKET(R)

desc: COUVERCLE

1шт.

14

2160-1230

BUSHING;RUBBER

desc: GARNIYURE CAOUTCHOUC

1шт.

19

S0511853

BOLT M10X1.5X20

desc: BOULON A 6 PANS

4шт.

20

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

21

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

24

S5000113

WASHER;PLAIN M4

desc: RONDELLE PLATE

2шт.

25

S3458843

SCREW M5X0.8X14

desc: VIS

12шт.

26

S5000213

WASHER;PLAIN M5

desc: RONDELLE PLATE

12шт.

27

S5102203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

12шт.

28

2906-9004

ASHTRAY

desc: CENDRIER

1шт.

30

S5020313

WASHER;PLAIN M6

desc: RONDELLE PLATE

2шт.

31

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

40

S3458583

SCREW M4X0.7X12

desc: VIS

2шт.

41

S5102103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

4шт.

79

2161-2072

RUBBER;BUSHING

SERIAL: 1-8

1шт.

79

2161-1228

RUBBER;BUSHING

SERIAL: 9

1шт.

80

2191-3977

PLATE

desc: PLAQUE

1шт.

81

2621-3365

COVER

SERIAL: 1-8

1шт.

81

2621-3365A

COVER

SERIAL: 9

1шт.

82

S3458983

SCREW M6X1.0X20

desc: VIS

2шт.
