Запчасти Doosan Daewoo AIRCONDITIONER BODY PARTS

-

2920-1064

COOLER & HEATER ASS'Y

SC: D

-2шт.

1

2208-6010A

COMPRESSOR V-5. B-TYPE

SERIAL: 1-8

1шт.

1

2208-6010B

COMPRESSOR V-5. B-TYPE

SERIAL: 9

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

7шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

7шт.

4

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

3шт.

5

2185-1370A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE COMPRESSEUR

1шт.

6

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

7

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS CREUX

5шт.

8

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

5шт.

9

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

5шт.

10

2520-6003

CONDENSER ASS'Y

SERIAL: 1-158

1шт.

10

2520-6003A

CONDENSER ASS'Y

SERIAL: 159

1шт.

11

2195-3938A

BRACKET;CONDENSER(L.H.)

desc: SUPPORT

1шт.

12

2195-3937

BRACKET;CONDENSER(R.H.)

desc: SUPPORT

1шт.

13

S0553553

BOLT M6X1.0X45

desc: BOULON A 6 PANS

4шт.

14

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

15

S5010313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

16

S4012333

NUT M6X1.0

desc: ECROU

6шт.

17

2185-1369D14

HOSE;LIQUID(1) L450

desc: TUYAU FLEXIBLE

1шт.

18

2185-1369D5

HOSE;LIQUID(2) L700

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

19

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

20

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

21

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

22

2195-3829

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

23

S0758253

BOLT M10X1.25X35

desc: BOULON A 6 PANS

1шт.

24

S0758853

BOLT M10X1.25X65

desc: BOULON A 6 PANS

1шт.

25

S0759753

BOLT M10X1.25X110

desc: BOULON A 6 PANS

1шт.

26

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

27

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

28

2195-3909

HOLDER;COMPRESSOR(F)

SERIAL: 1-8

1шт.

28

2195-3909A

HOLDER;COMPRESSOR(F)

SERIAL: 9

1шт.

29

2195-3911

HOLDER;COMPRESSOR(R)

SERIAL: 1-8

1шт.

29

2195-3911A

HOLDER;COMPRESSOR(R)

SERIAL: 9

1шт.

30

2120-1036D13

BOLT M10X1.5X165

desc: BOULON A 6 PANS

1шт.

31

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

32

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

33

S4012633

NUT M10X1.5

desc: ECROU

1шт.

34

2195-3912A

HOLDER;AIRCON

desc: POSSESSEUR

1шт.

35

2195-3910

SUPPORT;AIRCON

desc: SUPPORT

1шт.

36

S0512053

BOLT M10X1.5X25

desc: BOULON A 6 PANS

1шт.

37

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

38

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

39

2195-3934

SUPPORT;ALTERNATOR

desc: SUPPORT

1шт.

40

2106-1016D8

V-BELT;ALT B-925

SERIAL: 1-68

1шт.

40

2106-1021D8

V-BELT;ALT B-925

SERIAL: 69

1шт.

41

2107-1020

PULLEY;ADAPTER

desc: POULIE

1шт.

42

S0556253

BOLT M8X1.25X45

desc: BOULON A 6 PANS

4шт.

43

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

44

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

45

2106-1016D4

V-BELT;AIR-CON B-1300

SERIAL: 1-68

1шт.

45

2106-1021D4

V-BELT;AIR-CON B-1300

SERIAL: 69

1шт.

46

2920-9031B

AIR HANDLING UNIT

desc: UNITE

1шт.

46A

2545-6020

RESISTOR ASS'Y

desc: . RESISTANCE

1шт.

46B

2538-6012

BLOWER MOTOR

desc: . MOTEUR

1шт.

46C

2547-6030

THERMISTOR

desc: . THERMOSTAT

1шт.

46D

2920-6121

EVAPORATOR CORE

desc: . CHAUFFAGE

1шт.

46E

2920-6120

HEATER CORE ASS'Y

desc: . CHAUFFAGE

1шт.

47

2191-1374D12

PLATE

desc: PLAQUE

2шт.

48

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

49

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

50

2114-1058D29

WASHER Ґх26/Ґх9

desc: RONDELLE PLATE

4шт.

51

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

52

2543-9027

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

53

S3450563

SCREW M4X0.7X8

desc: VIS

2шт.

54

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.

59

2124-1084D3

CLIP L250

desc: ATTACHE

15шт.

60

S0758353

BOLT M10X1.25X40

desc: BOULON A 6 PANS

1шт.
