Запчасти Doosan Daewoo PROPELLING PIPING POWER TRAIN

-

400-00950

PROPELLING PIPING

SERIAL: 1449

-2шт.

1

423-00159

BLOCK

SC: D

2шт.

3

S8000231

O-RING

desc: JOINT TORIQUE

5шт.

4

2180-1026D19

O-RING

desc: JOINT TORIQUE

1шт.

5

S2217266

BOLT;SOCKET M12X1.75X130

desc: BOULON A 6 PANS CREUX

6шт.

6

S5110703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

7

DS2023100

HOSE

desc: TUYAU FLEXIBLE

2шт.

10

S2215866

BOLT;SOCKET M12X1.75X130

desc: BOULON A 6 PANS CREUX

2шт.

11

S8030121

O-RING

desc: JOINT TORIQUE

4шт.

12

2181-4133D31

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

13

2181-4133D13

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

14

2181-1126D1

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

15

S8180291

PACKING

desc: RONDELLE

1шт.

16

2181-1126D7

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

17

S8000141

O-RING

desc: JOINT TORIQUE

1шт.

18

2181-1917D1

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

21

2184-1096D124

HOSE

desc: TUYAU FLEXIBLE

1шт.

23

2184-1076D143

HOSE

desc: TUYAU FLEXIBLE

1шт.
