Запчасти Doosan Daewoo CONTROL VALVE-BOOM SWING HYDRAULIC PARTS
№
Артикул
Название
Примечание
Количество
-
2420-9618
CONTROL VALVE
SERIAL: 1001-1136
1шт.
-
2420-9618A
CONTROL VALVE
SERIAL: 1137-1298
1шт.
-
2420-9618B
CONTROL VALVE
SERIAL: 1299-1371
1шт.
-
2420-9618C
CONTROL VALVE
SERIAL: 1372
1шт.
1
2-01-955
COVER;END
desc: COUVERCLE
1шт.
2
4-01-969
BLOCK ASS'Y-BOOM SWING
desc: BLOC
1шт.
2-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
2-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
2-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
2-14
S8000111
O-RING
desc: . JOINT TORIQUE
1шт.
2-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
2-18
4-01-90101
ANTI-CAVITATION VALVE
desc: . VANNE
1шт.
2-19
S8000141
O-RING
desc: .. JOINT TORIQUE
1шт.
3
4-01-968
BLOCK ASS'Y-SWING
desc: BLOC
1шт.
3-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
3-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
3-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
3-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
3-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
3-16
S8000141
O-RING 1BP-14
desc: . JOINT TORIQUE
1шт.
3-17
2-09-908
PLUG
desc: . BOUCHON
1шт.
4
4-01-967
BLOCK ASS'Y-DOZER
desc: BLOC
1шт.
4-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
4-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
4-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
4-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
4-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
4-16
S8000141
O-RING 1BP-14
desc: . JOINT TORIQUE
2шт.
4-17
2-09-908
PLUG
desc: . BOUCHON
2шт.
5
4-01-941A
INLET ASS'Y(P3)
desc: BLOC
1шт.
5-2
S8000241
O-RING P24
desc: . JOINT TORIQUE
1шт.
5-3
2430-1067
PLUG
desc: . BOUCHON
1шт.
5-4
S8000181
O-RING 1BP-18
desc: . JOINT TORIQUE
1шт.
5-5
2430-1050
PLUG
desc: . BOUCHON
1шт.
5-6
4-02-901
MAIN RELIEF VALVE
desc: . BATI PRINCIPAL
1шт.
5-7
S8000221
O-RING
desc: .. JOINT TORIQUE
1шт.
6
4-01-966
BLOCK ASS'Y-BOOM2
desc: BLOC
1шт.
6-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
6-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
6-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
6-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
6-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
6-16
S8000141
O-RING 1BP-14
desc: . JOINT TORIQUE
2шт.
6-17
2-09-908
PLUG;CHECK
desc: . BOUCHON
2шт.
7
4-01-965
BLOCK ASS'Y-ARM1
desc: BLOC
1шт.
7-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
7-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
2шт.
7-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
2шт.
7-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
2шт.
7-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
2шт.
7-16
4-02-902
OVERLOAD RELIEF VALVE
desc: . CLAPET DE DECHARGE
2шт.
7-17
S8000141
O-RING
desc: .. JOINT TORIQUE
1шт.
8
4-01-96401
BLOCK ASS'Y-TRAVEL1
desc: BLOC
1шт.
8-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
8-12
2-05-906
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
8-13
1-51-908
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
8-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
8-15
2-09-901
PLUG;CHECK
desc: . BOUCHON
1шт.
9
4-01-93301
INLET ASS'Y(P1 P2)
desc: BLOC
1шт.
9-4
2-03-904
CASE;FILTER
desc: . CARTER
1шт.
9-5
S8000121
O-RING
desc: . JOINT TORIQUE
1шт.
9-6
1-59-902
FILTER
desc: . FILTRE
1шт.
9-13
2-05-904
CHECK;POPPET
desc: . CARTOCHE DE POPPET
2шт.
9-14
1-51-512
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
2шт.
9-15
S8000141
O-RING
desc: . JOINT TORIQUE
2шт.
9-16
2-09-903
PLUG;CHECK
desc: . BOUCHON
2шт.
9-17
2430-1058
PLUG
desc: . BOUCHON
2шт.
9-18
S8000141
O-RING
desc: . JOINT TORIQUE
2шт.
9-20
4-02-901
MAIN RELIEF VALVE
desc: . BATI PRINCIPAL
1шт.
9-20A
S8000221
O-RING
desc: .. JOINT TORIQUE
1шт.
9-20B
AS568-015
O-RING
desc: .. JOINT TORIQUE
1шт.
9-20C
1-57-903
RING;BACK UP
desc: .. RONDELLE D'APPUI
1шт.
10
4-01-96402
BLOCK ASS'Y-TRAVEL2
desc: BLOC
1шт.
10-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
10-12
2-05-906
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
10-13
1-51-908
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
10-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
10-15
2-09-901
PLUG;CHECK
desc: . BOUCHON
1шт.
11
4-01-915
BLOCK ASS'Y-BOOM1
desc: BLOC
1шт.
11-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
11-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
11-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
11-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
11-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
11-16
4-02-902
OVERLOAD RELIEF VALVE
desc: . CLAPET DE DECHARGE
2шт.
11-16A
S8000141
O-RING
desc: .. JOINT TORIQUE
1шт.
12
4-01-962
BLOCK ASS'Y-BUCKET
desc: BLOC
1шт.
12-7
1-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
12-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
12-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
12-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
12-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
12-16
4-02-902
OVERLOAD RELIEF VALVE
desc: . CLAPET DE DECHARGE
1шт.
12-16A
S8000141
O-RING
desc: .. JOINT TORIQUE
1шт.
12-17
4-01-90101
ANTI-CAVITATION VALVE
desc: . VANNE
1шт.
12-17A
S8000141
O-RING
desc: .. JOINT TORIQUE
1шт.
13
4-01-96125
BLOCK ASS'Y-ARM2
desc: BLOC
1шт.
13-7
4-54-119
O-RING
desc: . JOINT TORIQUE
2шт.
13-12
2-05-905
CHECK;POPPET
desc: . CARTOCHE DE POPPET
1шт.
13-13
1-51-907
CHECK;SPRING
desc: . CARTOCHE DE RESSORT
1шт.
13-14
S8000111
O-RING 1BP-11
desc: . JOINT TORIQUE
1шт.
13-15
2-09-902
PLUG;CHECK
desc: . BOUCHON
1шт.
13-16
S8000181
O-RING 1BP-18
desc: . JOINT TORIQUE
1шт.
13-17
2430-1050
PLUG
desc: . BOUCHON
1шт.
14
2-01-942
COVER;END
desc: COUVERCLE
1шт.
15
1-55-228
O-RING
desc: JOINT TORIQUE
13шт.
16
S8000181
O-RING 1BP-18
desc: JOINT TORIQUE
7шт.
17
2-20-902
BOLT;TIE 186L
desc: BOULON A 6 PANS
4шт.
18
2-20-903
BOLT;TIE 310L
desc: BOULON A 6 PANS
4шт.
19
S4010503
NUT
desc: ECROU
8шт.
Выбрано товаров: 110
