Запчасти Doosan Daewoo ROTARY GROUP-TRAVEL MOTOR HYDRAULIC PARTS

-

09610741

ROTARY GROUP

SERIAL: 1449

1шт.

1

09604145

ROTARY GROUP

desc: GROUPE ROTATOIRE

1шт.

1A

09603779

ROTARY GROUP. HYDR. SECTION

desc: . GROUPE ROTATOIRE

1шт.

1Aa

09421289

CYLINDER

desc: .. VERIN

1шт.

1Ab

09921787

LENS;CONTROL

desc: .. LENS

1шт.

1Ac

09921508

PIN;CENTER

desc: .. GOUPILLE

1шт.

1Ad

02021902

PISTON & PISTON RINGS

desc: .. BOUCLE

7шт.

1Ad1

09443336

PISTON

desc: ... PISTON

1шт.

1Ad2

09831893

RING;STEEL SEALING

desc: ... BAGUE

2шт.

1Ae

09921526

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Ae

09921527

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Ae

09921528

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Ae

09921529

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Ae

09921530

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Ae

09921534

SHIM;ADJUSTMENT

desc: .. CALE

1шт.

1Af

09921507

SPRING;PRESSURE

desc: .. CALE

1шт.

1Ag

09062847

PLATE;RETAINING

desc: .. PLAQUE

1шт.

1Ah

09831106

SCREW;PAN HEAD

desc: .. VIS

14шт.

1B

09921893

SHAFT;DRIVE

desc: . ARBRE

1шт.

1C

09651516

SHIM

desc: . CALE

1шт.

1D

09921488

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921489

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921490

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921491

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921492

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921493

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921494

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1D

09921495

PLATE;BACK-UP

desc: . PLAT DE SECOURS

1шт.

1E

09083365

RING;RETAINING

desc: . BAGUE D'ETANCHEITE

1шт.

1F

09154382

BEARING;TAPERED-ROLLER

desc: . PALIER

1шт.

1G

09154293

BEARING;TAPERED-ROLLER

desc: . PALIER

1шт.

2

09604037

CONTROL

desc: REGULATEUR

1шт.

5

09156651

HOUSING

desc: CARTER

1шт.

8

09083412

SCREW;LOCKING

desc: VIS

1шт.

9

09831178

RING;RETAINING

desc: ARRET

1шт.

10

09087188

RING;SHAFT SEAL

desc: RONDELLE

1шт.

11

09156591

PLATE;BACK-UP

desc: PLAQUE

1шт.

12

09156591

O-RING

desc: JOINT TORIQUE

1шт.

13

09156651

SCREW;LOCKING

desc: VIS

1шт.

17

09446862

PIN;THREADED

desc: GOUPILLE

2шт.

17

09086120

PIN;THREADED

SC: R

1шт.

17

09083530

PIN;THREADED

SC: R

1шт.

17

09085976

PIN;THREADED

SC: R

1шт.

17

09153075

PIN;THREADED

SC: R

1шт.

17

09154041

PIN;THREADED

SC: R

1шт.

17

09153975

PIN;THREADED

SC: R

1шт.

17

09154212

PIN;THREADED

SC: R

1шт.

18

09152459

NUT;SEAL LOCK

desc: ECROU

2шт.
