Запчасти Doosan Daewoo REAR AXLE(4) HYDRAULIC PARTS

1

001.05.1125

O-RING

desc: JOINT TORIQUE

2шт.

2

171.07.008.01

BUSHING;REDUCTION

desc: MANCHON DE REDUCTION

2шт.

3

001.05.1358

O-RING

desc: JOINT TORIQUE

4шт.

4

738.07.026.07

LEVER

desc: LEVIER

2шт.

5

171.07.007.01

WASHER

desc: RONDELLE

2шт.

6

016.06.0439

BOLT

desc: VIS A TETE CONIQUE

2шт.

7

016.13.0488

BOLT

desc: POINTEAU FILETE

2шт.

8

738.07.018.02

PUSHER

desc: POINTEAU

4шт.

9

171.07.003.02

PISTON

desc: PISTON

6шт.

10

738.07.009.01

O-RING

desc: JOINT TORIQUE

6шт.

11

738.07.010.01

RING;BACK UP

desc: BAUGE ANTIEXTRUSION

6шт.

12

171.07.009.02

BOLT

desc: VIS DE REGLAGE

6шт.

13

171.07.010.01

SPRING

desc: RESSORT

6шт.

14

001.05.1357

O-RING

desc: JOINT TORIQUE

6шт.

15

006.02.0193

NUT

desc: ECROU

6шт.

16

171.07.002.03

DISC;INTERMEDIATE BRAKE

desc: DISQUE INTERMEDIAIRE

8шт.

17

734.07.015.01

PLUG

desc: BOUCHON

2шт.

18

734.07.014.01

BOLT

desc: VIS DE PURGE

2шт.

19

171.07.610.03

DISC;BRAKE

desc: DISQUE DE FREIN

8шт.

20

171.07.004.03

DISC;BRAKE(LEFT)

desc: DISQUE DE FREIN

1шт.

21

171.07.004.04

DISC;BRAKE(RIGHT)

desc: DISQUE DE FREIN

1шт.

22

015.01.0361

PLUG

desc: BOUCHON

2шт.

23

171.07.707.01

LEVER(RIGHT)

desc: LEVIER

1шт.

24

171.07.706.01

LEVER(LEFT)

desc: LEVIER

1шт.

25

171.07.036.01

STOP(RIGHT)

desc: ARRET

1шт.

26

016.06.2600

BOLT

desc: VIS

4шт.

27

016.12.0454

BOLT

desc: POINTEAU FILETE

2шт.

28

006.03.0195

NUT

desc: ECROU

2шт.

29

171.07.036.02

STOP(LEFT)

desc: ARRET

1шт.

30

171.07.011.01

SPACER

desc: ENTRETOISE

2шт.

31

016.01.2758

BOLT

desc: VIS

1шт.

32

171.07.703.01

SUPPORT

desc: SUPPORT

1шт.

33

006.03.1196

NUT

desc: ECROU

2шт.

34

171.07.620.03

CYLINDER;WHEEL

desc: CYLINDRE FREIN

1шт.

35

002.01.0502

CIRCLIP

desc: ARRETOIR

2шт.

36

734.07.031.01

SPACER

desc: ENTRETOISE

2шт.

37

008.01.0212

FITTING;GREASE

desc: GRAISSEUR

2шт.
