Запчасти Doosan Daewoo ELECTRIC BOX-STAND ASSY BODY PARTS

-

195-00309

STAND ASS'Y

SERIAL: 1001-1348

-2шт.

-

195-00309A

STAND ASS'Y

SERIAL: 1349

-2шт.

1

512-00006

ELECTRIC BOX ASS'Y

desc: EQUIPMENT ELECTRIQUE

1шт.

1-1

2512-1135B

ELECTRIC BOX

desc: . EQUIPMENT ELECTRIQUE

1шт.

1-2

2627-1208A

COVER

desc: . COUVERCLE

1шт.

1-3

159-00015

COVER

desc: . COUVERCLE

1шт.

1-4

2159-1210A

PLATE;SEAT

desc: . PLAQUE

1шт.

1-5

2159-1211B

PLATE

desc: . PLAQUE

1шт.

1-6

2159-1209

COVER

desc: . COUVERCLE

1шт.

1-7

-

CUSHION;RUBBER 20T

desc: . CAOUTCHOUC

2шт.

1-8

2120-2166D2

BOLT

desc: . BOULON A 6 PANS

4шт.

1-10

2114-1898D1

WASHER M10

desc: . RONDELLE

4шт.

1-11

2120-2166D16

BOLT M8X1.25X25

desc: . BOULON A 6 PANS

2шт.

1-13

2114-1898D2

WASHER M8

desc: . RONDELLE

2шт.

1-14

2120-2166D6

SCREW M6X1.0X16

desc: . BOULON A 6 PANS

12шт.

1-16

2114-1898D3

WASHER M6

desc: . RONDELLE

10шт.

1-17

2120-2166D31

SCREW M5X0.8X12

desc: . VIS

4шт.

1-19

2114-1898D4

WASHER M5

desc: . RONDELLE

4шт.

1-20

2197-2416A

BRACKET

desc: . SUPPORT

1шт.

1-21

2114-1898D5

WASHER

desc: . RONDELE

2шт.

2

2901-9027

SEAT

desc: SIEGE

1шт.

3

S2208761

BOLT;SOCKET M8X1.25X18

desc: BOULON A 6 PANS CREUX

4шт.

30

S5020313

WASHER;PLAIN M6

desc: RONDELLE

7шт.

31

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

5шт.

33

2549-9139

MICRO SWITCH

desc: COMMUTATEUR MICRO

1шт.

34

2159-1220

PLATE

desc: PLAQUE

1шт.

35

2120-2166D21

BOLT M4X0.7X25

desc: BOULON A 6 PANS

2шт.

36

2114-1898D13

WASHER M4

desc: RONDELLE PLATE

2шт.

38

2120-2166D4

BOLT M10X1.5X20

desc: BOULON A 6 PANS

10шт.

41

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

7шт.

44

2114-1898D1

WASHER M10

desc: RONDELLE

10шт.

45

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.

48

2530-1782

HARNESS;MICRO S/W

desc: FAISCEAU

1шт.

51

2181-2743A

CONNECTOR

desc: CONNECTEUR

1шт.

52

S3051023

BOLT;WING M8X1.25X80

desc: BOULON A 6 PANS

1шт.

53

2114-1868

WASHER

desc: RONDELLE PLATE

1шт.

54

2621-2641A

COVER

desc: COUVERCLE

1шт.

55

2621-3847

COVER

desc: COUVERCLE

1шт.

58

4415-9006A

NOZZLE;AIR

desc: BUSE

1шт.

61

2197-2315E

BRACKET

desc: SUPPORT

1шт.

63

2197-2332

BRACKET

desc: SUPPORT

1шт.

64

2185-1634A

DUCT;HOT AIR

desc: CONDUITE

1шт.

67

S2800

CLAMP

desc: ATTACHE

2шт.

68

S3640173

SCREW;TAPPING

desc: VIS TARAUDEUSE

2шт.

69

5901-1093

BELT;SEAT

desc: COURROIE

1шт.

75

195-01256

BRACKET

desc: SUPPORT

1шт.

76

161-00108A

RUBBER

desc: CAOUTCHOUC

1шт.

77

2158-1017D1

PROTECTOR

desc: TUYAU FLEXIBLE

1шт.
