Запчасти Doosan Daewoo COMPRESSOR ASSY BODY PARTS

-

208-00001

COMPRESSOR ASS'Y

SC: D

-2шт.

1

2208-6012B

COMPRESSOR

desc: COMPRESSEUR

1шт.

2

S2212261

BOLT;SOCKET M10X1.5X50

ICA: Y

3шт.

2

S2212266

BOLT;SOCKET M10X1.5X50

desc: BOULON A 6 PANS CREUX

3шт.

3

S5110601

WASHER;SPRING M10

ICA: Y

4шт.

3

S5110603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

5

195-00228C

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

6

195-00229B

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

7

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

3шт.

8

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

13шт.

9

S0556753

BOLT M8X1.25X70

desc: BOULON A 6 PANS

1шт.

10

195-00654

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

11

S5010513

WASHER;PLAIN M8

desc: RONDELLE

1шт.

12

2106-1021D18

V-BELT 1590L(AIR COMP.)

desc: COURROIE

1шт.

13

2107-1015A

PULLEY ASS'Y;IDLE

SERIAL: 1001-1173

1шт.

13

2107-1015B

PULLEY ASS'Y;IDLE

SERIAL: 1174

1шт.

14

S0513253

BOLT M10X1.5X80

desc: BOULON A 6 PANS

1шт.

15

S4032633

NUT

desc: ECROU

1шт.

16

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

6шт.

17

107-00022A

PULLEY ASS'Y

SERIAL: 1001-1318

1шт.

17

107-00022B

PULLEY ASS'Y

SERIAL: 1319

1шт.

18

114-00342

SPACER

SERIAL: 1001-1318

1шт.

18

114-00342A

SPACER

SERIAL: 1319

1шт.

19

S0558353

BOLT M10X1.5X35

desc: BOULON A 6 PANS

1шт.

20

2114-1058D63

WASHER

desc: RONDELLE

1шт.
