Запчасти Doosan Daewoo AIRCONDITIONER BODY PARTS

-

920-00016

COOLER & HEATER PIPING

SC: D

-2шт.

1

2920-9032B

UNIT;AIR HANDLING

SERIAL: 1001-1253

1шт.

1

2920-9032C

UNIT;AIR HANDLING

SERIAL: 1254

1шт.

1A

2545-6019

RESISTOR ASS'Y

desc: . RESISTANCE

1шт.

1B

2538-6011

BLOWER MOTOR

desc: . MOTEUR

1шт.

1C

2547-6030

THERMISTOR

desc: . THERMOSTAT

1шт.

1D

2920-6121

EVAPORATOR CORE

desc: . CHAUFFAGE

1шт.

1E

2920-6120

HEATER CORE ASS'Y

desc: . CHAUFFAGE

1шт.

2

2191-1374D12

PLATE

desc: PLAQUE

4шт.

3

2161-2272

PLATE;RUBBER

desc: PLAQUE

4шт.

4

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

5

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

6

S5010513

WASHER;PLAIN M8

desc: RONDELLE

4шт.

8

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

9

185-00036C

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE

1шт.

10

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

1шт.

11

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

12

S5020603

WASHER;PLAIN M10

desc: RONDELLE

1шт.

13

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

14

185-00188

HOSE;LIQUID(1) 850L

desc: TUYAU FLEXIBLE

1шт.

15

185-00064D2

HOSE;LIQUID(2) 2500L

desc: TUYAU FLEXIBLE

1шт.

18

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

19

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

20

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

21

2161-1908D3

PLATE;RUBBER

SERIAL: 1001-1092

2шт.

21

2161-1908D2

PLATE;RUBBER

SERIAL: 1093

2шт.

22

2124-1509D2

CLIP D18/M8

desc: ATTACHE

3шт.

23

2124-1509D3

CLIP D24/M8

desc: ATTACHE

3шт.

24

2124-1509D5

CLIP D36/M8

desc: ATTACHE DE TUYAU

4шт.

25

2124-1622D3

CLIP;BAND 280L

desc: ATTACHE

4шт.

26

2121-1305

NUT

desc: ECROU

3шт.

27

2120-2172

BOLT;STUD M10X1.25X25

SERIAL: 1001-1092

1шт.

27

120-00246

BOLT;STUD M10X1.25X15

SERIAL: 1093

1шт.

28

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.
