Запчасти Doosan Daewoo MAIN PUMP - GEAR PUMP(1) HYDRAULIC PARTS

1

H9309R9326-0

PUMP;GEAR

desc: POMPE PIGNON

1шт.

2

1100570835

FRAME;FRONT

desc: BATI AUTORADIO

1шт.

3

1100448792

CASE;GEAR

desc: CARTER

1шт.

5

1100530194

GEAR;DRIVING

desc: PIGNON

1шт.

6

1100338291

GEAR;IDLE

desc: PIGNON

1шт.

7

4100343731

SIDE PLATE ASS'Y

desc: PLAQUE LATERALE

2шт.

10

1164034001

PLATE

desc: PLAQUE

1шт.

11

1164035004

GUIDE

desc: GUIDE

2шт.

12

1100397492

COUPLING

desc: ACCOUPLEMENT

1шт.

13

1100452241

BUSH

desc: COUSSINET

1шт.

14

1100022822

O-RING

desc: JOINT TORIQUE

2шт.

15

1301163001

O-RING

desc: JOINT TORIQUE

3шт.

16

1100026237

COUP RING;RING

desc: BAGUE

2шт.

17

1100219199

COUP RING;RING

desc: BAGUE

2шт.

18

1100452819

BOLT;HEX M10X95

desc: BOULON A 6 PANS

4шт.

19

1301588006

BOLT;HEX SOCKET M10X25

desc: BOULON A 6 PANS

2шт.

20

1100022804

PIN;PARALLEL

desc: GOUPILLE

4шт.

24

1300053004

O-RING

desc: JOINT TORIQUE

1шт.

25

1300073008

O-RING

desc: JOINT TORIQUE

2шт.

26

1300205003

O-RING

desc: JOINT TORIQUE

1шт.
