Запчасти Doosan Daewoo STEERING ASSЎЇY BODY PARTS

-

300-00017

STEERING ASS'Y

SC: D

-2шт.

1

303-00015

COLUMN;STEERING

desc: COLONNE

1шт.

2

154-00005

WHEEL;STEERING

desc: RIM

1шт.

2A

-

WHEEL

desc: . RIM

1шт.

2B

0047.0064

CAP;WHEEL

desc: . CHAPEAU

1шт.

3

190-00138

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

4

S2212766

BOLT;SOCKET M10X1.5X55

desc: BOULON A 6 PANS

4шт.

5

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

6

2420-9579

VALVE;STEERING

desc: VANNE DE DIRECTION

1шт.

7

195-02186

BRACKET;STEER

desc: SUPPORT

1шт.

8

S0515053

BOLT M12X1.75X25

desc: BOULON A 6 PANS

4шт.

9

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

10

195-02332

BRACKET;COLUMN

desc: SUPPORT

1шт.

11

S4012633

NUT

desc: ECROU

4шт.

12

2114-1898D16

WASHER

desc: RONDELLE

4шт.

13

S5110601

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

14

S0558453

BOLT M10X1.5X45

desc: BOULON A 6 PANS

4шт.

15

4161-9036

MOUNT;FLEX

desc: ENSEMBLE SUPPORT DE MONTAGE

4шт.

16

161-00521

FOAM;SPONGE

desc: EPONGE

1шт.
