Запчасти Doosan Daewoo ENGINE MOUNTING(1)-CUSHION BODY PARTS

-

201-00177

ENGINE MOUNTING ASS'Y

SC: D

-2шт.

1

201-00173

ENGINE

SERIAL: 1001-1357

1шт.

1

201-00173A

ENGINE

SERIAL: 1358

1шт.

14

S5010913

WASHER;PLAIN

desc: RONDELLE PLATE

8шт.

17

161-00270

RUBBER;E/G MOUNT(FRONT)

desc: CAOUTCHOUC

1шт.

18

161-00271

RUBBER;E/G MOUNT(REAR)

desc: CAOUTCHOUC

3шт.

20

S0766461

BOLT M16X1.5X110

desc: BOULON A 6 PANS

3шт.

24

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

16шт.

26

195-01404

BRACKET;ENGINE

desc: SUPPORT

1шт.

27

195-01403

BRACKET;ENGINE

desc: SUPPORT

1шт.

30

S0766361

BOLT M16X1.5X105

desc: BOULON A 6 PANS

1шт.

31

S0514953

BOLT M12X1.75X22

desc: BOULON A 6 PANS

8шт.

32

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

4шт.

33

S0512263

BOLT M10X1.5X30

desc: BOULON A 6 PANS

16шт.

39

114-00547

WASHER

desc: RONDELLE

8шт.

56

195-01076A

BRACKET;MOUNTING(FRONT;L.H.)

desc: SUPPORT

1шт.

61

195-01091B

BRACKET;MOUNTING(FRONT;R.H.)

desc: SUPPORT

1шт.

74

121-00035

NUT;LOCK

desc: ECROU

4шт.
