Запчасти Doosan Daewoo ELECTRIC BOX ASSY BODY PARTS

-

500-00224A

ELECTRIC PLATE ASS'Y

SERIAL: 1001-1296

1шт.

-

500-00224B

ELECTRIC PLATE ASS'Y

SERIAL: 1297-1779

1шт.

-

500-00224C

ELECTRIC PLATE ASS'Y

SERIAL: 1780

1шт.

1

512-00035A

PLATE;ELECTRIC

desc: PLAQUE

1шт.

2

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

3

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

4шт.

4

2516-1104

BUZZER;PILOT

desc: COMMANDE VIBREUR

1шт.

5

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

2шт.

6

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

7

570-00001

BOX;FUSE

SERIAL: 1001-1296

1шт.

7

570-00001A

BOX;FUSE

SERIAL: 1297

1шт.

8

190-01053

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

9

S3450983

SCREW M6X1.0X20

desc: VIS

2шт.

10

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

11

2525-1012

UNIT;BLINK 12V

desc: FUSIBLE

1шт.

12

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

1шт.

13

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

14

543-00080

UNIT;CONTROL

desc: UNITE DE COMMANDE

1шт.

15

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

16

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

17

543-00042

CONTROLLER;AIRCON

desc: COMMANDE DEMARREUR

1шт.

18

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

19

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

20

2523-9005

CONTROLLER;STARTER

desc: COMMANDE DEMARREUR

1шт.

21

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

22

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

23

537-00070A

TIMER;WIPER

desc: TIMER ESSUIE-GLACE

1шт.

24

S3450953

SCREW M6X1.0X12

desc: VIS

2шт.

25

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

26

537-00010

TIMER;PREHEAT

desc: TEMPORISATEUR

1шт.

27

S3450943

SCREW M6X1.0X10

desc: VIS M6X1.0X10

1шт.

28

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.

29

2544-9032

RELAY;LAMP

desc: UNITE

1шт.

30

2544-9032

RELAY;E/G STOP

desc: RELAIS

1шт.

31

2544-9032

RELAY;HORN

desc: UNITE

1шт.

32

2544-9032

RELAY;BREAKER

desc: UNITE

1шт.

33

2544-9032

RELAY;PILOT

desc: UNITE

1шт.

34

2544-9032

RELAY;FORWARD

desc: UNITE

1шт.

35

2544-9032

RELAY;REVERSE

desc: UNITE

1шт.

36

2544-9032

RELAY;TRAVEL

desc: UNITE

1шт.

37

2544-9032

RELAY;WORKING LAMP

desc: UNITE

1шт.

38

S3450823

SCREW M5X0.8X10

desc: VIS

4шт.

39

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

4шт.

40

2190-2037D66

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

41

2190-2037D59

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

42

2190-2037D60

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

43

530-00343A

HARNESS;ELECTRIC BOX

SERIAL: 1001-1296

1шт.

43

530-00343B

HARNESS;ELECTRIC BOX

SERIAL: 1297-1779

1шт.

43

530-00343C

HARNESS;ELECTRIC BOX

SERIAL: 1780

1шт.

44

124-00208D4

CLIP 26/M8

desc: ATTACHE

2шт.

45

2121-1305

NUT M8

desc: ECROU

2шт.

46

2124-1622D1

CLIP;BAND

desc: ATTACHE

10шт.

47

545-00007

RESISTOR ASS'Y

desc: RESISTANCE

1шт.

48

S3450333

SCREW M3X0.5X8

desc: VIS

2шт.

49

S5100003

WASHER;SPRING M3

desc: RONDELLE ELASTIQUE

2шт.

50

2544-9032

RELAY;BOOM SWING

desc: RELAIS

1шт.

51

2190-2037D67

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

52

537-00071

TIMER;E/G STOP

desc: TEMPORISATEUR

1шт.

53

S3450953

SCREW M6X1.0X12

desc: VIS

1шт.

54

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

1шт.
