Запчасти Doosan Daewoo COMPRESSOR BODY PARTS

-

208-00003A

COMPRESSOR MTG

SC: D

-2шт.

1

2208-6012B

COMPRESSOR ASS'Y

desc: COMPRESSEUR

1шт.

2

107-00028A

IDLE PULLEY ASS'Y

desc: POULIE

1шт.

3

2106-1021D19

V-BELT;AIRCON

desc: COURROIE

1шт.

4

195-01090E

BRACKET;PULLEY

desc: SUPPORT

1шт.

5

S0556453

BOLT M8X1.25X55

desc: BOULON A 6 PANS

4шт.

6

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

10шт.

7

S2212466

BOLT;SOCKET M8X1.5X40

desc: BOULON A 6PANS

3шт.

8

S5110603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

9

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

3шт.

10

S0513253

BOLT

desc: BOULON A 6 PANS

1шт.

11

S4012633

NUT

desc: ECROU

1шт.

12

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

4шт.

13

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

14

2114-1058D29

WASHER

desc: RONDELLE

2шт.

15

195-01112C

BRACKET;COMPRESSOR

desc: SUPPORT

1шт.

16

621-01475C

COVER

desc: COUVERCLE

1шт.

17

S0508853

BOLT M8X1.25X20

desc: BOULON A 6 PANS

2шт.
