Запчасти Doosan Daewoo AIR CONDITIONER(1)-RELATED PARTS BODY PARTS

-

920-00101

COOLER ASS'Y

SC: D

-2шт.

1

920-00047

UNIT;AIRCON

desc: UNITE D'AIRCON

1шт.

1A

2545-6019

RESISTOR ASS'Y

desc: . RESISTANCE

1шт.

1B

2538-6011

BLOWER MOTOR

desc: . MOTEUR

1шт.

1C

2547-6030

THERMISTOR

desc: . THERMOSTAT

1шт.

2

2191-1374D12

PLATE

desc: PLAQUE

2шт.

3

2161-2272

PLATE;RUBBER

desc: PLAQUE

2шт.

4

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

2шт.

5

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

6

S5010513

WASHER;PLAIN M8

desc: RONDELLE PLATE

2шт.

7

185-00363A

HOSE;DISCHARGE

SERIAL: 1001-1448

1шт.

7

185-00363B

HOSE;DISCHARGE

SERIAL: 1449

1шт.

7A

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.

8

185-00362

HOSE;SUCTION

desc: TUYAU FLEXIBLE

1шт.

8A

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

9

S2212361

BOLT;SOCKET M10X1.5X35

desc: BOULON A 6 PANS

1шт.

10

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

12

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

14

2185-1369D17

HOSE;LIQUID(2) 3200L

desc: TUYAU FLEXIBLE

1шт.

15

2204-6032

DRIER;RECEIVER

desc: RESERVOIR DESSICATEUR

1шт.

16

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

17

S0504553

BOLT M6X1.0X14

desc: BOULON A 6 PANS

2шт.

18

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

29

124-00208D2

CLIP

desc: ATTACHE

1шт.

30

124-00209D1

CLIP

desc: ATTACHE

3шт.

31

2120-2187

BOLT;STUD M8X1.25X12

desc: BOULON A 6 PANS

2шт.

32

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

3шт.

33

2121-1305

NUT M8

desc: ECROU

3шт.

34

S0508653

BOLT M8X1.25X18

desc: BOULON A 6 PANS

1шт.
