Запчасти Doosan Daewoo HEATER PIPING UPPER STRUCTURE

-

2920-1078

COOLER & HEATER ASS'Y

SC: D

-2шт.

14

2124-1622D3

CLIP;BAND L280

desc: ATTACHE

4шт.

20

2124-1024D3

CLAMP;HOSE D16-D22

desc: COLLIER

4шт.

21

2186-9003

VALVE PT3/8

SERIAL: 1-2345

2шт.

21

186-00014

COCK;DRAIN

SERIAL: 2346

2шт.

22

2181-1113D17

REDUCER PT3/8X3/8

desc: REDUCTEUR

1шт.

23

2185-1308D3

HOSE;HEATER L2300

desc: TUYAU FLEXIBLE

1шт.

24

2185-1308D23

HOSE;HEATER L1200

desc: TUYAU FLEXIBLE

1шт.

25

2124-1509D3

CLIP D24/M8

desc: ATTACHE

2шт.

26

2121-1305

NUT M8X1.25

desc: ECROU

2шт.

27

S0509053

BOLT M8X1.25X25

desc: BOULON A 6 PANS

4шт.

28

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

29

S5010513

WASHER;PLAIN

desc: RONDELLE

4шт.
