Запчасти Doosan Daewoo ELECTRIC BOX UPPER STRUCTURE

-

2197-2236

STAND ASS'Y

SERIAL: 1-990

-2шт.

1

2512-1123A

ELECTRIC BOX ASS'Y

desc: SUPPORT

1шт.

1-1

2512-1121A

ELECTRIC BOX

desc: . EQUIPMENT ELECTRIQUE

1шт.

1-2

2621-3796A

COVER

desc: . COUVERCLE

1шт.

1-3

2621-3797A

COVER

desc: . COUVERCLE

1шт.

1-4

2159-1175A

PLATE;SEAT

desc: . PLAQUE

1шт.

1-5

2159-1176A

PLATE;STAND

desc: . PLAQUE

1шт.

1-6

2621-3832A

COVER

desc: . COUVERCLE

1шт.

1-7

2159-1173A

PLATE;UPPER

desc: . PLAQUE

1шт.

1-8

2159-1174A

PLATE;LOWER

desc: . PLAQUE

1шт.

1-9

2190-3156A

PLATE;NAME

desc: . PLAQUE D'IDENTIFICATION

1шт.

1-10

-

CUSHION RUBBER 20T

desc: . CAOUTCHOUC

4шт.

1-11

S0511853

BOLT M10X1.5X20

desc: . BOULON A 6 PANS

5шт.

1-12

S5102603

WASHER;SPRING M10

desc: . RONDELLE ELASTIQUE

5шт.

1-13

S5010613

WASHER M10

desc: . RONDELLE PLATE

5шт.

1-14

S5102503

WASHER;SPRING M8

desc: . RONDELLE ELASTIQUE

4шт.

1-15

S5010513

WASHER M8

desc: . RONDELLE PLATE

4шт.

1-16

S0509053

BOLT M8X1.25X25

desc: . BOULON A 6 PANS

4шт.

1-17

S0504553

BOLT M6X1.0X14

desc: . BOULON A 6 PANS

15шт.

1-18

S5100303

WASHER;SPRING M6

desc: . RONDELLE ELASTIQUE

15шт.

1-19

S5010313

WASHER M6

desc: . RONDELLE ELASTIQUE

15шт.

1-20

S3450853

SCREW M5X0.8X16

desc: . VIS

4шт.

1-21

S5100203

WASHER;SPRING M5

desc: . RONDELLE ELASTIQUE

4шт.

1-22

S5000213

WASHER M5

desc: . RONDELLE PLATE

4шт.

1-23

2197-1839

BRACKET

desc: . SUPPORT

1шт.

2

2901-9027

SEAT

desc: SIEGE

1шт.

3

2901-9007

BELT;SAFETY

desc: COURROIE

1шт.

4

2120-2191

BOLT

desc: BOULON A 6 PANS

2шт.

5

S4012533

NUT

desc: ECROU

4шт.

13

2158-1017D3

PROTECTOR

desc: PROTECTEUR

1шт.

14

S3200

CLAMP;HOSE

desc: COLLIER

2шт.

17

S5010513

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

18

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE

5шт.

21

S0508953

BOLT

desc: BOULON A 6 PANS

4шт.

29

S4012333

NUT M6X1.0

desc: ECROU

2шт.

30

S5020313

WASHER;PLAIN M6

desc: RONDELLE PLATE

6шт.

31

S5110303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

6шт.

38

S0515153

BOLT M12X1.75X28

desc: BOULON A 6 PANS

5шт.

39

S5010713

WASHER;PLAIN M12

desc: RONDELLE PLATE

5шт.

40

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

6шт.

41

S0504653

BOLT M6X1.0X16

desc: BOULON A 6 PANS

2шт.

42

2472-1054B

CASE;FILTER

desc: CARTER

1шт.

43

S5735241

PIN;SPLIT

desc: GOUPILLE FENDUE

1шт.

44

4139-9067

CABLE;CONTROL

desc: CABLE DE COMMANDE

1шт.

45

4116-1478A

PLATE

desc: PLAQUE

1шт.

46

S3450973

SCREW M6X1.0X16

desc: VIS

2шт.

47

4549-9107

SWITCH;FRESH AIR

desc: INTERRUPTEUR

1шт.

48

2114-1058D46

WASHER

desc: RONDELLE PLATE

1шт.

60

2181-2649

CONNECTOR

desc: RACCORD

1шт.

61

S3051023

BOLT;WING M8X1.25X80

desc: BOULON A 6 PANS

1шт.

62

2114-1868

WASHER PL3

desc: RONDELLE PLATE

1шт.

63

2190-2049

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

64

2621-2641A

COVER

desc: COUVERCLE

1шт.

65

2621-3847

COVER

desc: COUVERCLE

1шт.

66

S0504453

BOLT M6X1.0X12

desc: BOULON A 6 PANS

2шт.

81

2891-1498

PLATE

desc: PLAQUE

1шт.

82

2891-1499

PLATE

desc: PLAQUE

1шт.

83

2891-1500

PLATE

desc: PLAQUE

1шт.
