Запчасти Doosan Daewoo AIR CONDITIONER UPPER STRUCTURE

-

2920-1078

COOLER & HEATER ASS'Y

SC: D

-2шт.

1

2185-1690

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE

1шт.

1

2185-1690A

HOSE;COMPRESSOR

desc: TUYAU FLEXIBLE

1шт.

1

2185-1690B

HOSE;COMPRESSOR

SERIAL: 233

1шт.

2

S2212261

BOLT;SOCKET M10X1.5X30

desc: BOULON A 6 PANS CREUX

1шт.

3

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

4

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

5

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

6

2185-1369D5

HOSE;LIQUID(1) L700

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

7

2185-1369D9

HOSE;LIQUID(2) L2000

SERIAL: 1-287

1шт.

7

2185-1369D16

HOSE;LIQUID(2) L1400

SERIAL: 288

1шт.

8

2204-6032

RECEIVER DRIER

desc: RESERVOIR DESSICATEUR

1шт.

9

2514-6001

HOLDER;RECEIVER DRIER

desc: POSSESSEUR

1шт.

10

S0504853

BOLT M6X1.0X20

desc: BOULON A 6 PANS

2шт.

11

2920-9032A

UNIT;AIR HANDLING 12V

desc: CLE A MOLETTE

1шт.

12

2191-1374D12

PLATE

desc: PLAQUE

4шт.

13

2161-2272

PLATE;RUBBER

desc: PLAQUE

4шт.

14

2124-1622D3

CLIP;BAND L280

desc: ATTACHE

6шт.

15

2549-1132D2

SWITCH;AIRCON

desc: INTERRUPTEUR

1шт.

16

2544-9019

RELAY;AIRCON

SERIAL: 1-609

1шт.

16

2544-9032

RELAY;AIRCON

SERIAL: 610

1шт.

17

2543-9028

CONTROLLER;AIRCON

desc: MODULE DE COMMANDE

1шт.

18

S3450583

SCREW M4X0.7X12

desc: VIS

2шт.

19

S5100103

WASHER;SPRING M4

desc: RONDELLE ELASTIQUE

2шт.
