Запчасти Doosan Daewoo MAIN PUMP-CONTROL PISTON HYDRAULIC PARTS

-

4100531167

CONTROL PISTON ASS'Y

SERIAL: 1-525

1шт.

1

1100534307

CYLINDER

desc: CYLINDRE

1шт.

2

1100531151

PISTON 29 CM3

desc: PISTON

2шт.

3

1100486354

PISTON 8.5X50

desc: PISTON

1шт.

4

1301589009

H.S.H. CAP SCREW M10X30

desc: VIS A 6 PANS

2шт.

5

1301187007

O-RING 1B P16 15.8X2.4

SC: K

1шт.

6

1100382344

ORIFICE

desc: ORIFICE

1шт.

7

1301193002

O-RING 1B P20 19.8X2.4

SC: K

2шт.

8

1100407737

CONED DISC SPRING

desc: RESSORT

4шт.

9

1700606257

SPRING 27.8/2.5X31/2.5

desc: RESSORT

2шт.

11

1163027002

PLUG GIA

desc: BOUCHON

2шт.

12

1301223002

O-RING 1B P29 28.7X3.5

SC: K

2шт.
