Запчасти Doosan Daewoo SWING REDUCTION GEAR HYDRAULIC PARTS

-

2101-9002

REDUCTION GEAR ASS'Y

SERIAL: 1-242

1шт.

-

2101-9002A

REDUCTION GEAR ASS'Y

SERIAL: 243-427

1шт.

-

2101-9002B

REDUCTION GEAR ASS'Y

SERIAL: 428-615

1шт.

-

2101-9002C

REDUCTION GEAR ASS'Y

SERIAL: 616

1шт.

1

2405-1009

SHAFT

desc: ARBRE

1шт.

2

2114-1632

COLLAR

desc: RONDELLE DE BUTEE

1шт.

3

2412-1026

PLATE

desc: PLAQUE

1шт.

4

2109-9041

BEARING;TAPER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.

5

2402-1033

CASE;GEAR

SERIAL: 1-242

1шт.

5

2402-1033A

CASE;GEAR

SERIAL: 243-427

1шт.

5

2402-1033B

CASE;GEAR

SERIAL: 428

1шт.

6

2181-1116D1

PLUG PT1/8

desc: BOUCHON

2шт.

7

2180-9154

SEAL;OIL D90XD65

SC: K

1шт.

8

2109-9042

BEARING TAPER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.

9

2114-1633

COLLAR

desc: RONDELLE DE BUTEE

1шт.

10

2123-1778

PIN

desc: BROCHE

1шт.

11

2432-1014

CARRIER ASS'Y 2

desc: ENSEMBLE SUPPORT

1шт.

11-1

2514-1010

CARRIER(NO.2)

desc: . ENSEMBLE SUPPORT

1шт.

11-2

2112-1205

SHAFT 2

desc: . ARBRE

3шт.

11-3

2110-1204

BUSH

SC: D

3шт.

11-4

2404-1044

PLANETARY(NO.2)

desc: . PLANETAIRE

3шт.

11-5

2412-1029

PLATE;THRUST

desc: . PLAQUE

3шт.

11-6

S5741162

PIN;SPRING

desc: . BROUCHE

3шт.

12

2404-1040

GEAR;SUN 22

desc: PIGNON PRINCIPAL

1шт.

13

2404-1041

GEAR;RING

desc: COURONNE DENTEE

1шт.

14

2432-1015

CARRIER ASS'Y 1

desc: ENSEMBLE SUPPORT

1шт.

14-1

2514-1009

CARRIER(NO.1)

desc: . ENSEMBLE SUPPORT

1шт.

14-2

2412-1028

PLATE;THRUST

desc: . PLAQUE

3шт.

14-3

2404-1043

PLANETARY(NO.2)

desc: . PLANETAIRE

3шт.

14-4

2112-1203

SHAFT 1

desc: . ARBRE

3шт.

14-5

2412-1027

PLATE;THRUST

desc: . PLAQUE

1шт.

15

2404-1042

GEAR;SUN 1

desc: PIGNON PRINCIPAL

1шт.

16

2120-1445

BOLT;SOCKET M12X1.75X95

desc: BOULON A 6 PANS CREUX

6шт.

17

2181-1116D6

PLUG PT3/8

desc: BOUCHON

1шт.

18

2180-1220

PACKING

SC: K

1шт.
