Запчасти Doosan Daewoo REMOTE CONTROL VALVE HYDRAULIC PARTS

-

2420-9518B

JOYSTICK ASS'Y(L.H.)

SERIAL: 3039

1шт.

-

2420-9519B

JOYSTICK ASS'Y(R.H.)

SERIAL: 3039

1шт.

1

JA1G1001

CASE

desc: CARTER

1шт.

2

WPT18

PLUG

desc: BOUCHON

4шт.

3

J95C1002

PLUG

desc: BOUCHON

1шт.

4

P0014

O-RING

desc: JONT TORIQUE

1шт.

5

J95C1003

SPOOL PF3/8

desc: BOBINE

4шт.

6

J95C1004

SHIM

SC: R

-2шт.

7

J95C1005

SPRING

desc: RESSORT

4шт.

8

J95C1006

SEAT;SPRING

desc: SIEGE

4шт.

9

J24D2011

STOPPER

desc: ARRET

4шт.

10

JA0J1001

SPRING

desc: RESSORT

4шт.

11

J95C1008

PLUG

desc: BOUCHON

4шт.

12

PSY10

SEAL;ROD

desc: JOINT

4шт.

13

P0020

O-RING

desc: JONT TORIQUE

4шт.

14

J95C1009

ROD;BUSH

desc: TIGE DE POUSSOIR

4шт.

15

JA1G1002

PLATE

desc: PLAQUE

1шт.

16

J97A5018

BOOT

desc: GAINE DE PROTECTION

1шт.

17

J95C1012

JOINT ASS'Y

desc: ENSEMBLE DE JOINT

1шт.

18

JA1G1004

PLATE;SWASH

desc: PLAQUE

1шт.

19

J95C1014

NUT;HEX

desc: ECROU

1шт.

20

HNM14-1

NUT M14X2.0

desc: ECROU

1шт.

21

P0010A

O-RING

desc: JONT TORIQUE

1шт.

22

J97A1001

HANDLE;CONNECTOR

desc: RACCORD

1шт.

23

J97A1002

BOOT(R.H.)

desc: GAINE DE PROTECTION

1шт.

23

J97A1003

BOOT(L.H.)

desc: GAINE DE PROTECTION

1шт.

24

HNM12-1

NUT M12X1.25

desc: ECROU

1шт.

25

J97A1004

SWITCH ASS'Y

desc: INTERRUPTEUR

1шт.

26

J97A1005

INSERT

desc: INSERT

1шт.

27

J97A1006

HANDEL ASS'Y

desc: HANDLE ASS'Y

1шт.

28

SAM103

SCREW;TAPPING

desc: VIS TARAUDEUSE

1шт.

29

J95C1011

BUSHING

desc: DOUILLE

1шт.

30

JA1J2001

SPOOL KIT

desc: BARBOTIN

1шт.

31

JA1G3002

PLUG KIT

desc: BOUCHON

1шт.

32

J95C1012LK

HANDLE KIT(L.H)

desc: POIGNEE

1шт.

32

J95C1012RK

HANDLE KIT(R.H)

desc: POIGNEE

1шт.
