Запчасти Doosan Daewoo BUCKET FRONT ATTACHMENTS

-

2704-1483

BUCKET ASS'Y-0.15§©

SERIAL: 1-97

1шт.

-

2704-1483A

BUCKET ASS'Y-0.15§©

SERIAL: 98-212

1шт.

-

2704-1483B

BUCKET ASS'Y-0.15§©

SERIAL: 213-437

1шт.

-

2704-1483C

BUCKET ASS'Y-0.15§©

SERIAL: 438

1шт.

1

2704-1482

BUCKET ASS'Y-0.15§©

SERIAL: 1-97

1шт.

1

2704-1482A

BUCKET ASS'Y-0.15§©

SERIAL: 98-212

1шт.

1

2704-1482B

BUCKET ASS'Y-0.15§©

SERIAL: 213-437

1шт.

1

2704-1482C

BUCKET ASS'Y-0.15§©

SERIAL: 438

1шт.

1A

2713-9009

ADAPTER

SERIAL: 1-437

5шт.

1A

2713-9050

ADAPTER

SERIAL: 438

5шт.

2

2713-9010

POINT;TOOTH

SERIAL: 1-437

5шт.

2

2713-9051

POINT;TOOTH

SERIAL: 438

5шт.

3

2705-9005

PIN;LOCK

desc: GOUPILLE DE BLOCAGE

5шт.

4

2705-9006

PIN;LOCK RUBBER

desc: BROCHE

5шт.

5

2713-6051

CUTTER;SIDE(L.H.)

desc: COUTEAU LATERAL

1шт.

6

2713-6050

CUTTER;SIDE(R.H.)

desc: COUTEAU LATERAL

1шт.

7

S0565261

BOLT M16X2.0X50

desc: BOULON A 6 PANS

6шт.

8

S4012923

NUT M16X2.0

desc: ECROU

6шт.

9

S5102901

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

6шт.
