Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

897219-0010

CASE;TIMING GEAR

desc: CARTER

1шт.

11

897160-6290

PLATE;REAR

desc: PLAQUE

1шт.

15A

509000-2270

BOLT M12X25

desc: BOULON A 6 PANS

3шт.

15A

050041-2300

BOLT M12X30

desc: BOULON A 6 PANS

2шт.

15B

050041-0250

BOLT M10X25

desc: BOULON A 6 PANS

3шт.

32

897117-2420

GASKET;GEAR CASE

desc: JOINT

1шт.

36

050040-8200

BOLT;GEAR CASE M8X20

desc: BOULON A 6 PANS

6шт.

36

050040-8450

BOLT;GEAR CASE M8X45

desc: BOULON A 6 PANS

2шт.

38

908151-0200

PIN O.D10X20L

desc: BROCHE

2шт.

49

894140-1171

O-RING;CASE TO COVER

desc: JOINT TORIQUE

1шт.

54

894155-3602

COVER;GEAR CASE

desc: COUVERCLE

1шт.

57

511321-0090

COVER;TIMING CHECK HOLE

desc: COUVERCLE

2шт.

58

028080-6120

BOLT;CHECK HOLE M6X12

desc: BOULON A 6 PANS

4шт.

60

028080-8300

BOLT;COVER M8X30

desc: BOULON A 6 PANS

8шт.

62

995821-2550

BOLT;COVER M12X55

desc: BOULON A 6 PANS

1шт.

65

897118-6980

GASKET;COVER

desc: JOINT

2шт.

68

894155-7211

COVER;GEAR CASE

desc: COUVERCLE

1шт.

73

028680-6160

BOLT;COVER FIX

desc: BOULON A 6 PANS

4шт.

82

909160-7080

WASHER

desc: RONDELLE PLATE

1шт.

103

509625-0790

SEAL;OIL FRONT

desc: JOINT D'HUILE

1шт.

175

897071-5611

SEAL;OIL REAR

desc: JOINT

1шт.

289

909150-5100

WASHER

desc: RONDELLE ELASTIQUE

1шт.
