Запчасти Doosan Daewoo RADIATOR ASSY BODY PARTS

-

202-00056C

RADIATOR ASS'Y

SERIAL: 32761-35149

1шт.

-

202-00056E

RADIATOR ASS'Y

SERIAL: 35150

1шт.

1

13F41000

RADIATOR

desc: RADIATEUR

1шт.

2

13F42000

COOLER;OIL

desc: REFRIGERATION

1шт.

3

13F43000

FRAME

desc: CHASSIS

1шт.

4

13F44000

SHROUD

desc: MONTURE

1шт.

5

13F45000

GUARD;FAN

desc: GARDE

1шт.

6

13C45000

NET;WIRE

desc: FILET DE FIL

2шт.

7

P06

CAP

desc: CHAPEAU

1шт.

8

P04

COCK;DRAIN

desc: ROBINET

1шт.

9

P03-2

HOSE;DRAIN

desc: TUYAU FLEXIBLE

1шт.

10

P1106

BOLT;WING

desc: BOULON A 6PANS

4шт.

11

P1306

WASHER;PLAIN

desc: RONDELLE

4шт.

12

P1406

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

13

P1108

BOLT M8X1.25X15

desc: BOULON A 6PANS

6шт.

14

P1110A

BOLT M10X1.25X25

desc: BOULON A 6PANS

12шт.

15

P22

SPONGE

desc: MOUSSE DE CAOUTCHOUC

2шт.

16

P1110B

BOLT;HAX M10X1.25X30L

desc: BOULON A 6PANS

2шт.

17

P1310

WASHER;PLAIN M10

desc: RONDELLE

2шт.

18

P1410

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

2шт.
