Запчасти Doosan Daewoo ENGINE MOUNTING(1)-CUSHION BODY PARTS

-

201-00065A

ENGINE MOUNTING

SERIAL: 20001-35149

-2шт.

-

K1005206A

ENGINE MOUNTING

SERIAL: 35150

-2шт.

1

201-00116

ENGINE

SERIAL: 20001-31890

1шт.

1

201-00166A

ENGINE TIER-II

SERIAL: 31891-33124

1шт.

1

201-00166B

ENGINE TIER-II

SERIAL: 33125

1шт.

17

161-00270

RUBBER;MOUNTING(FRONT)

desc: CAOUTCHOUC

1шт.

18

161-00271

RUBBER;MOUNTING(REAR)

desc: CAOUTCHOUC

3шт.

20

S0766461

BOLT M16X1.5X110

desc: BOULON A 6PANS

3шт.

24

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

18шт.

26

195-01404

BRACKET;MOUNTING(REAR-R.H.)

desc: SUPPORT

1шт.

27

195-01403

BRACKET;MOUNTING(REAR-L.H.)

desc: SUPPORT

1шт.

31

S0514953

BOLT M12X1.75X22

desc: BOULON A 6PANS

8шт.

32

S5102703

WASHER;SPRING M12

desc: RONDELLE ELASTIQUE

8шт.

33

S0512263

BOLT M10X1.5X30

desc: BOULON A 6PANS

18шт.

56

195-01076A

BRACKET;MOUNTING(FRONT-R.H.)

desc: SUPPORT

1шт.

61

195-01091B

BRACKET;MOUNTING(FRONT-L.H.)

desc: SUPPORT

1шт.

74

121-00035

NUT;LOCK

desc: ECROU

4шт.

82

114-00416A

WASHER

desc: RONDELLE

8шт.

83

S0766361

BOLT M16X1.5X105

desc: BOULON A 6PANS

1шт.

89

S5010913

WASHER M16

desc: RONDELLE PLATE

8шт.
