Запчасти Doosan Daewoo AIRCONDITIONER(1)-RELATED PARTS BODY PARTS

-

920-00049

COOLER ASS'Y

SERIAL: 20001-32114

-2шт.

-

920-00122

COOLER ASS'Y

SERIAL: 32115

-2шт.

1

920-00047

UNIT;AIRCON

desc: CLE A MOLETTE

1шт.

1A

2545-6019

RESISTOR ASS'Y

desc: . RESISTANCE

1шт.

1B

2538-6011

BLOWER MOTOR

desc: . MOTEUR

1шт.

1C

2547-6030

THERMISTOR

desc: . THERMOSTAT

1шт.

2

2191-1374D12

PLATE

desc: PLAQUE

2шт.

3

2161-2272

PLATE;RUBBER

desc: PLAQUE

2шт.

4

S0509053

BOLT M8X1.25X25

desc: BOULON A 6PANS

2шт.

5

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

2шт.

6

S5010513

WASHER;PLAIN M8

desc: RONDELLE

2шт.

7

2124-1024D3

CLAMP;HOSE

desc: COLLIER

2шт.

8

185-00196C

HOSE;COMPRESSOR

SERIAL: 20001-31000

1шт.

8

185-00370

HOSE;DISCHARGE

SERIAL: 31001

1шт.

8A

1.161-00018

CAP;CHECK PORT(H)

desc: . CHAPEAU

1шт.

9

S2212261

BOLT;SOCKET M10X1.5X30

SERIAL: 20001-31040

1шт.

9

S2212366

BOLT;SOCKET M10X1.5X35

SERIAL: 31041

1шт.

10

S5110601

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

1шт.

11

S5020603

WASHER;PLAIN M10

desc: RONDELLE PLATE

1шт.

12

2180-1219

WASHER;SEAL

desc: RONDELLE D'ETANCHEITE

2шт.

13

2185-1369D15

HOSE;LIQUID(1)-350L

SERIAL: 20001-32114

1шт.

13

185-00360D1

HOSE;LIQUID(1)-400L

SERIAL: 32115

1шт.

14

2185-1369D3

HOSE;LIQUID(2)-2500L

desc: TUYAU FLEXIBLE LIQUIDE

1шт.

15

2204-6032

DRIER;RECEIVER

desc: RESERVOIR DESSICATEUR

1шт.

16

2514-6001

HOLDER;RECEVIER DRIER

desc: POSSESSEUR

1шт.

17

S0504853

BOLT M6X1.0X20

desc: BOULON A 6PANS

2шт.

31

2161-1908D2

PLATE;RUBBER

desc: PLAQUE

1шт.

32

2124-1509D3

CLIP ҐХ24/M8

desc: ATTACHE

3шт.

33

2121-1305

NUT M8X1.25

desc: ECROU

2шт.

34

S0508453

BOLT M8X1.25X12

desc: BOULON A 6PANS

1шт.

35

S5102503

WASHER;SPRING M8

desc: RONDELLE ELASTIQUE

1шт.

36

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

2шт.

38

2124-1622D3

CLIP;BAND

desc: ATTACHE

2шт.

40

185-00371

HOSE;SUCTION

SERIAL: 31001

1шт.

40A

1.161-00019

CAP;CHECK PORT(L)

desc: . CHAPEAU

1шт.
