Запчасти Doosan Daewoo CONTROL VALVE(2) HYDRAULIC PARTS

-

420-00280A

CONTROL VALVE

desc: DISTRIBUTEUR

1шт.

1

C0151-61003

HOUSING;VALVE

SC: D

1шт.

2

C0151-61004

HOUSING;VALVE

SC: D

1шт.

3

C017B-71501

SPOOL KIT (ARM-2)

desc: BOBINE

1шт.

4

C017B-71502

SPOOL KIT (BUCKET)

desc: BOBINE

1шт.

5

C017B-71503

SPOOL KIT (BOOM-1)

desc: BOBINE

1шт.

6

C017B-71504

SPOOL KIT (TRAVEL)

desc: BOBINE

2шт.

7

C017B-71505

SPOOL KIT (TRAVEL STRAIGHT)

desc: BOBINE

1шт.

8

C017B-71506

SPOOL KIT (ARM-1)

desc: BOBINE

1шт.

9

C017B-71513

SPOOL KIT (OPTION)

desc: BOBINE

1шт.

10

C017B-71507

SPOOL KIT (BOOM-2)

desc: BOBINE

1шт.

11

C017B-71508

SPOOL KIT (SWING)

desc: BOBINE

1шт.

12

C0001-63001

CAP

desc: CHAPEAU

9шт.

13

C0001-63002

CAP

desc: CHAPEAU

9шт.

14

95121-05500

O-RING

SC: K

20шт.

20

C017B-71517

SPOOL KIT

desc: BOBINE

1шт.

21

21111-30702

SEAT;SPRING

desc: PLAQUE DE VANNE

3шт.

22

T1461-16002

SPRING

desc: RESSORT

1шт.

23

T1152-33301

PLUG

desc: BOUCHON

1шт.

24

C017B-71518

SPOOL KIT

desc: BOBINE

2шт.

25

T1461-20005

SPRING

desc: RESSORT

2шт.

26

21001-00213

O-RING

SC: K

2шт.

27

21111-55956

PLUG

desc: BOUCHON

2шт.

29

21111-56512

SPRING

desc: RESSORT

2шт.

30

T1411-18004

POPPET

desc: POPPET

1шт.

49

C011B-40377

OVERLOAD RELIEF VALVE ASS'Y

desc: CLAPET DE DECHARGE

1шт.

50

C0003-60001

RELIEF VALVE ASS'Y

desc: CLAPET DE DECHARGE

2шт.

58

C0003-01209

PLUG ASS'Y

desc: BOUCHON

1шт.

59

21003-00383

PLUG ASS'Y

desc: BOUCHON

1шт.

60

21003-00382

PLUG ASS'Y

desc: BOUCHON

2шт.

61

21003-00384

PLUG ASS'Y

desc: BOUCHON

2шт.

62

21003-00385

PLUG ASS'Y

desc: BOUCHON

2шт.

69

T1411-18006

POPPET

desc: POPPET

1шт.

76

T1515-22001

O-RING

desc: JONT TORIQUE

4шт.

77

T1515-10001

O-RING

SC: K

3шт.

78

T1515-30001

O-RING

SC: K

10шт.

79

21001-00182

O-RING

SC: K

1шт.

80

C0001-63003

CAP

desc: CHAPEAU

1шт.

81

C0001-63005

CAP

desc: CHAPEAU

1шт.
