Запчасти Doosan Daewoo COOLING WATER PUMP ENGINE PARTS
15
1
17
14
13
3
6
5
2
7
9
4
12
8
10
11
16
1
65.06500-6157C
WATER PUMP ASS'Y
SERIAL: 021118
1шт.
1
65.06500-6157D
WATER PUMP ASS'Y
SERIAL: 040325
1шт.
1
REP_PNO: 65.91601-6003
-1шт.
1
65.06500-6357
WATER PUMP ASS'Y
SERIAL: 040715
1шт.
1
65.06500-6357A
WATER PUMP ASS'Y
SERIAL: 040716
1шт.
2
65.06501-0077B
HOUSING;WATER PUMP
SERIAL: 021118
1шт.
2
65.06501-0077C
HOUSING;WATER PUMP
SERIAL: 040325
1шт.
2
65.06501-0092
HOUSING;WATER PUMP
SERIAL: 040326
1шт.
3
65.06301-0673
PIPE;COOLING WATER
desc: . CONDUITE
1шт.
4
65.06505-0041
SHAFT
SERIAL: 040325
1шт.
4
65.06505-0026
SHAFT
SERIAL: 040715
1шт.
4
65.06505-0027
SHAFT
SERIAL: 040716
1шт.
5
65.06520-6007
SEAL;MECHANICAL
desc: . JOINT
1шт.
6
65.06506-0024A
IMPELLER
SERIAL: 040325
1шт.
6
65.06506-0027
IMPELLER
SERIAL: 040326
1шт.
7
65.01510-0103
SEAL;OIL
desc: . JOINT D'HUILE
1шт.
8
06.31420-4513
BEARING;BALL
desc: . PALIER
1шт.
9
65.06508-0012
SPACER
desc: . PALIER
1шт.
10
65.93410-0038
BEARING
desc: . PALIER
1шт.
11
06.29020-0131
RING;SNAP 52X2
desc: . CIRCLIP
1шт.
12
65.06507-0005A
GEAR;WATER PUMP DRIVE
desc: . PIGNON
1шт.
13
65.06901-0076
GASKET
desc: . RONDELLE DE BUTEE
1шт.
14
65.06512-0014
COVER
desc: . COUVERCLE
1шт.
15
06.01913-2914
BOLT ASS'Y M6X22
desc: . BOULON A 6PANS
5шт.
16
65.96501-0068
O-RING
desc: JONT TORIQUE
1шт.
17
06.01913-3234
BOLT ASS'Y M10X130
desc: BOULON A 6PANS
4шт.
