Запчасти Doosan Daewoo TRACK SPRING ASSY TRACK PARTS

1

274-00003A

TRACK SPRING ASS'Y

SERIAL: 1001-1161

2шт.

1

274-00003B

TRACK SPRING ASS'Y

SERIAL: 1162

2шт.

1-1

308-00030

BODY

desc: . CORPS

1шт.

1-2

195-02111

BRACKET

desc: . SUPPORT

1шт.

1-3

2444-6003B

ROD

desc: .. TIGE

1шт.

1-4

129-00147

SPRING

desc: . RESSORT

1шт.

1-5

2444-6004B

BAR;TIE

desc: . CAOUTCHOUC

1шт.

1-6

2121-6035A

NUT M76X2.0

desc: . ECROU

1шт.

1-7

-

PACKING;ROD D100XD120X12

SC: K

1шт.

1-8

-

RING;BACK UP 100X120X3

SC: K

1шт.

1-9

-

SEAL;DUST 100X114X8

SC: K

1шт.

1-10

2621-6019

PLATE

desc: . PLAQUE

1шт.

1-11

S0718361

BOLT M14X1.5X35

desc: . BOULON A 6 PANS

2шт.

1-12

S5102803

WASHER;SPRING M14

desc: . RONDELLE ELASTIQUE

2шт.

1-13

416-00017A

STOPPER

desc: . ARRET

1шт.

1-14

S5741420

PIN;SPRING D10X63

SERIAL: 1162

1шт.

1-15

308-00033A

BODY ASS'Y

desc: . ENSEMBLE DE CORPS

1шт.

*

2274-6014AKT

SEAL KIT

desc: KIT D'ETANCHEITE

1шт.
