Запчасти Doosan Daewoo MAIN PIPING-ONE & TWO WAY OPTION PARTS

-

400-00270

MAIN PIPING

SC: D

-2шт.

1

2420-9633

VALVE;SWITCH

SERIAL: 1001-1052

1шт.

1

2420-9633A

VALVE;SWITCH

SERIAL: 1053

1шт.

2

S0515353

BOLT M12X1.75X30

desc: BOULON A 6 PANS

2шт.

3

S5102703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

4

2181-4133D6

ADAPTER

desc: RACCORD ADAPTATEUR

3шт.

5

2181-2815D1

ELBOW

desc: COUDE

1шт.

6

2180-1026D19

O-RING

desc: JOINT TORIQUE

2шт.

7

S8030161

O-RING

desc: JOINT TORIQUE

8шт.

8

S8000291

O-RING

desc: JOINT TORIQUE

4шт.

9

140-00213A

PIPE

desc: TUYAU

2шт.

10

S2215461

BOLT;SOCKET M12X1.75X40

SERIAL: 1001-1064

8шт.

10

S2215466

BOLT;SOCKET M12X1.75X40

SERIAL: 1065

8шт.

11

S5110701

WASHER;SPRING M12

SERIAL: 1001-1064

8шт.

11

S5110703

WASHER;SPRING M12

SERIAL: 1065

8шт.

12

2184-1197D109

HOSE PF1-2100L

desc: TUYAU FLEXIBLE

1шт.

13

2184-1197D180

HOSE PF1-900L

desc: TUYAU FLEXIBLE

1шт.

14

2184-1197D114

HOSE PF1-1000L

desc: TUYAU FLEXIBLE

1шт.

15

2184-1212D49

HOSE PF1-1250L

desc: TUYAU FLEXIBLE

1шт.
